2: Making & Using Objects

This chapter will introduce enough C++ syntax and

program construction concepts to allow you to write

and run some simple object-oriented programs. In the

subsequent chapter we will cover the basic syntax of C

and C++ in detail.

By reading this chapter first, you'll get the basic flavor of what it is

like to program with objects in C++, and you'll also discover some

of the reasons for the enthusiasm surrounding this language. This

should be enough to carry you through Chapter 3, which can be a

bit exhausting since it contains most of the details of the C

language.

The user-defined data type, or class, is what distinguishes C++ from

traditional procedural languages. A class is a new data type that

you or someone else creates to solve a particular kind of problem.

Once a class is created, anyone can use it without knowing the

specifics of how it works, or even how classes are built. This

chapter treats classes as if they are just another built-in data type

available for use in programs.

Classes that someone else has created are typically packaged into a

library. This chapter uses several of the class libraries that come

with all C++ implementations. An especially important standard

library is iostreams, which (among other things) allow you to read

from files and the keyboard, and to write to files and the display.

You'll also see the very handy string class, and the vector container

from the Standard C++ Library. By the end of the chapter, you'll

see how easy it is to use a pre-defined library of classes.

In order to create your first program you must understand the tools

used to build applications.

The process of language translation

All computer languages are translated from something that tends

to be easy for a human to understand (source code) into something

that is executed on a computer (machine instructions). Traditionally,

translators fall into two classes: interpreters and compilers.

Thinking in C++

Interpreters

An interpreter translates source code into activities (which may

comprise groups of machine instructions) and immediately

executes those activities. BASIC, for example, has been a popular

interpreted language. Traditional BASIC interpreters translate and

execute one line at a time, and then forget that the line has been

translated. This makes them slow, since they must re-translate any

repeated code. BASIC has also been compiled, for speed. More

modern interpreters, such as those for the Python language,

translate the entire program into an intermediate language that is

then executed by a much faster interpreter1.

Interpreters have many advantages. The transition from writing

code to executing code is almost immediate, and the source code is

always available so the interpreter can be much more specific when

an error occurs. The benefits often cited for interpreters are ease of

interaction and rapid development (but not necessarily execution)

of programs.

Interpreted languages often have severe limitations when building

large projects (Python seems to be an exception to this). The

interpreter (or a reduced version) must always be in memory to

execute the code, and even the fastest interpreter may introduce

unacceptable speed restrictions. Most interpreters require that the

complete source code be brought into the interpreter all at once.

Not only does this introduce a space limitation, it can also cause

more difficult bugs if the language doesn't provide facilities to

localize the effect of different pieces of code.

1 The boundary between compilers and interpreters can tend to become a bit fuzzy,

especially with Python, which has many of the features and power of a compiled

language but the quick turnaround of an interpreted language.

2: Making & Using Objects

Compilers

A compiler translates source code directly into assembly language

or machine instructions. The eventual end product is a file or files

containing machine code. This is an involved process, and usually

takes several steps. The transition from writing code to executing

code is significantly longer with a compiler.

Depending on the acumen of the compiler writer, programs

generated by a compiler tend to require much less space to run, and

they run much more quickly. Although size and speed are

probably the most often cited reasons for using a compiler, in many

situations they aren't the most important reasons. Some languages

(such as C) are designed to allow pieces of a program to be

compiled independently. These pieces are eventually combined

into a final executable program by a tool called the linker. This

process is called separate compilation.

Separate compilation has many benefits. A program that, taken all

at once, would exceed the limits of the compiler or the compiling

environment can be compiled in pieces. Programs can be built and

tested one piece at a time. Once a piece is working, it can be saved

and treated as a building block. Collections of tested and working

pieces can be combined into libraries for use by other programmers.

As each piece is created, the complexity of the other pieces is

hidden. All these features support the creation of large programs2.

Compiler debugging features have improved significantly over

time. Early compilers only generated machine code, and the

programmer inserted print statements to see what was going on.

This is not always effective. Modern compilers can insert

information about the source code into the executable program.

This information is used by powerful source-level debuggers to show

2 Python is again an exception, since it also provides separate compilation.

Thinking in C++

exactly what is happening in a program by tracing its progress

through the source code.

Some compilers tackle the compilation-speed problem by

performing in-memory compilation. Most compilers work with files,

reading and writing them in each step of the compilation process.

In-memory compilers keep the compiler program in RAM. For

small programs, this can seem as responsive as an interpreter.

The compilation process

To program in C and C++, you need to understand the steps and

tools in the compilation process. Some languages (C and C++, in

particular) start compilation by running a preprocessor on the source

code. The preprocessor is a simple program that replaces patterns

in the source code with other patterns the programmer has defined

(using preprocessor directives). Preprocessor directives are used to

save typing and to increase the readability of the code. (Later in the

book, you'll learn how the design of C++ is meant to discourage

much of the use of the preprocessor, since it can cause subtle bugs.)

The pre-processed code is often written to an intermediate file.

Compilers usually do their work in two passes. The first pass parses

the pre-processed code. The compiler breaks the source code into

small units and organizes it into a structure called a tree. In the

expression "A + B" the elements `A', `+,' and `B' are leaves on the

parse tree.

A global optimizer is sometimes used between the first and second

passes to produce smaller, faster code.

In the second pass, the code generator walks through the parse tree

and generates either assembly language code or machine code for

the nodes of the tree. If the code generator creates assembly code,

the assembler must then be run. The end result in both cases is an

object module (a file that typically has an extension of .o or .obj). A

peephole optimizer is sometimes used in the second pass to look for

2: Making & Using Objects

pieces of code containing redundant assembly-language

statements.

The use of the word "object" to describe chunks of machine code is

an unfortunate artifact. The word came into use before object-

oriented programming was in general use. "Object" is used in the

same sense as "goal" when discussing compilation, while in object-

oriented programming it means "a thing with boundaries."

The linker combines a list of object modules into an executable

program that can be loaded and run by the operating system. When

a function in one object module makes a reference to a function or

variable in another object module, the linker resolves these

references; it makes sure that all the external functions and data

you claimed existed during compilation do exist. The linker also

adds a special object module to perform start-up activities.

The linker can search through special files called libraries in order to

resolve all its references. A library contains a collection of object

modules in a single file. A library is created and maintained by a

program called a librarian.

Static type checking

The compiler performs type checking during the first pass. Type

checking tests for the proper use of arguments in functions and

prevents many kinds of programming errors. Since type checking

occurs during compilation instead of when the program is running,

it is called static type checking.

Some object-oriented languages (notably Java) perform some type

checking at runtime (dynamic type checking). If combined with static

type checking, dynamic type checking is more powerful than static

type checking alone. However, it also adds overhead to program

execution.

C++ uses static type checking because the language cannot assume

any particular runtime support for bad operations. Static type

Thinking in C++

checking notifies the programmer about misuses of types during

compilation, and thus maximizes execution speed. As you learn

C++, you will see that most of the language design decisions favor

the same kind of high-speed, production-oriented programming

the C language is famous for.

You can disable static type checking in C++. You can also do your

own dynamic type checking you just need to write the code.

Tools for separate compilation

Separate compilation is particularly important when building large

projects. In C and C++, a program can be created in small,

manageable, independently tested pieces. The most fundamental

tool for breaking a program up into pieces is the ability to create

named subroutines or subprograms. In C and C++, a subprogram

is called a function, and functions are the pieces of code that can be

placed in different files, enabling separate compilation. Put another

way, the function is the atomic unit of code, since you cannot have

part of a function in one file and another part in a different file; the

entire function must be placed in a single file (although files can

and do contain more than one function).

When you call a function, you typically pass it some arguments,

which are values you'd like the function to work with during its

execution. When the function is finished, you typically get back a

return value, a value that the function hands back to you as a result.

It's also possible to write functions that take no arguments and

return no values.

To create a program with multiple files, functions in one file must

access functions and data in other files. When compiling a file, the

C or C++ compiler must know about the functions and data in the

other files, in particular their names and proper usage. The

compiler ensures that functions and data are used correctly. This

process of "telling the compiler" the names of external functions

2: Making & Using Objects

and data and what they should look like is called declaration. Once

you declare a function or variable, the compiler knows how to

check to make sure it is used properly.

Declarations vs. definitions

It's important to understand the difference between declarations and

definitions because these terms will be used precisely throughout

the book. Essentially all C and C++ programs require declarations.

Before you can write your first program, you need to understand

the proper way to write a declaration.

A declaration introduces a name an identifier to the compiler. It

tells the compiler "This function or this variable exists somewhere,

and here is what it should look like." A definition, on the other

hand, says: "Make this variable here" or "Make this function here."

It allocates storage for the name. This meaning works whether

you're talking about a variable or a function; in either case, at the

point of definition the compiler allocates storage. For a variable, the

compiler determines how big that variable is and causes space to be

generated in memory to hold the data for that variable. For a

function, the compiler generates code, which ends up occupying

storage in memory.

You can declare a variable or a function in many different places,

but there must be only one definition in C and C++ (this is

sometimes called the ODR: one-definition rule). When the linker is

uniting all the object modules, it will usually complain if it finds

more than one definition for the same function or variable.

A definition can also be a declaration. If the compiler hasn't seen

the name x before and you define int x;, the compiler sees the name

as a declaration and allocates storage for it all at once.

Function declaration syntax

A function declaration in C and C++ gives the function name, the

argument types passed to the function, and the return value of the

Thinking in C++

function. For example, here is a declaration for a function called

func1( )that takes two integer arguments (integers are denoted in

C/C++ with the keyword int) and returns an integer:

int func1(int,int);

The first keyword you see is the return value all by itself: int. The

arguments are enclosed in parentheses after the function name in

the order they are used. The semicolon indicates the end of a

statement; in this case, it tells the compiler "that's all there is no

function definition here!"

C and C++ declarations attempt to mimic the form of the item's

use. For example, if a is another integer the above function might

be used this way:

a = func1(2,3);

Since func1( ) returns an integer, the C or C++ compiler will check

the use of func1( )to make sure that a can accept the return value

and that the arguments are appropriate.

Arguments in function declarations may have names. The compiler

ignores the names but they can be helpful as mnemonic devices for

the user. For example, we can declare func1( )in a different fashion

that has the same meaning:

int func1(int length, int width);

A gotcha

There is a significant difference between C and C++ for functions

with empty argument lists. In C, the declaration:

int func2();

means "a function with any number and type of argument." This

prevents type-checking, so in C++ it means "a function with no

arguments."

2: Making & Using Objects

Function definitions

Function definitions look like function declarations except that they

have bodies. A body is a collection of statements enclosed in braces.

Braces denote the beginning and ending of a block of code. To give

func1( )a definition that is an empty body (a body containing no

code), write:

int func1(int length, int width) { }

Notice that in the function definition, the braces replace the

semicolon. Since braces surround a statement or group of

statements, you don't need a semicolon. Notice also that the

arguments in the function definition must have names if you want

to use the arguments in the function body (since they are never

used here, they are optional).

Variable declaration syntax

The meaning attributed to the phrase "variable declaration" has

historically been confusing and contradictory, and it's important

that you understand the correct definition so you can read code

properly. A variable declaration tells the compiler what a variable

looks like. It says, "I know you haven't seen this name before, but I

promise it exists someplace, and it's a variable of X type."

In a function declaration, you give a type (the return value), the

function name, the argument list, and a semicolon. That's enough

for the compiler to figure out that it's a declaration and what the

function should look like. By inference, a variable declaration might

be a type followed by a name. For example:

int a;

could declare the variable a as an integer, using the logic above.

Here's the conflict: there is enough information in the code above

for the compiler to create space for an integer called a, and that's

what happens. To resolve this dilemma, a keyword was necessary

for C and C++ to say "This is only a declaration; it's defined

Thinking in C++

elsewhere." The keyword is extern. It can mean the definition is

external to the file, or that the definition occurs later in the file.

Declaring a variable without defining it means using the extern

keyword before a description of the variable, like this:

extern int a;

extern can also apply to function declarations. For func1( ) it looks

like this:

extern int func1(int length, int width);

This statement is equivalent to the previous func1( )declarations.

Since there is no function body, the compiler must treat it as a

function declaration rather than a function definition. The extern

keyword is thus superfluous and optional for function declarations.

It is probably unfortunate that the designers of C did not require

the use of extern for function declarations; it would have been more

consistent and less confusing (but would have required more

typing, which probably explains the decision).

Here are some more examples of declarations:

//: C02:Declare.cpp

// Declaration & definition examples

extern int i; // Declaration without definition

extern float f(float); // Function declaration

float b; // Declaration & definition

float f(float a) { // Definition

return a + 1.0;

}

int i; // Definition

int h(int x) { // Declaration & definition

return x + 1;

}

int main() {

b = 1.0;

2: Making & Using Objects

i = 2;

f(b);

h(i);

} ///:~

In the function declarations, the argument identifiers are optional.

In the definitions, they are required (the identifiers are required

only in C, not C++).

Including headers

Most libraries contain significant numbers of functions and

variables. To save work and ensure consistency when making the

external declarations for these items, C and C++ use a device called

the header file. A header file is a file containing the external

declarations for a library; it conventionally has a file name

extension of `h', such as headerfile.h (You may also see some older

code using different extensions, such as .hxx or .hpp, but this is

becoming rare.)

The programmer who creates the library provides the header file.

To declare the functions and external variables in the library, the

user simply includes the header file. To include a header file, use

the #includepreprocessor directive. This tells the preprocessor to

open the named header file and insert its contents where the

#includestatement appears. A #includemay name a file in two

ways: in angle brackets (< >) or in double quotes.

File names in angle brackets, such as:

#include <header>

cause the preprocessor to search for the file in a way that is

particular to your implementation, but typically there's some kind

of "include search path" that you specify in your environment or

on the compiler command line. The mechanism for setting the

search path varies between machines, operating systems, and C++

implementations, and may require some investigation on your part.

File names in double quotes, such as:

Thinking in C++

#include "local.h"

tell the preprocessor to search for the file in (according to the

specification) an "implementation-defined way." What this

typically means is to search for the file relative to the current

directory. If the file is not found, then the include directive is

reprocessed as if it had angle brackets instead of quotes.

To include the iostream header file, you write:

#include <iostream>

The preprocessor will find the iostream header file (often in a

subdirectory called "include") and insert it.

Standard C++ include format

As C++ evolved, different compiler vendors chose different

extensions for file names. In addition, various operating systems

have different restrictions on file names, in particular on name

length. These issues caused source code portability problems. To

smooth over these rough edges, the standard uses a format that

allows file names longer than the notorious eight characters and

eliminates the extension. For example, instead of the old style of

including iostream.h which looks like this:

#include <iostream.h>

you can now write:

#include <iostream>

The translator can implement the include statements in a way that

suits the needs of that particular compiler and operating system, if

necessary truncating the name and adding an extension. Of course,

you can also copy the headers given you by your compiler vendor

to ones without extensions if you want to use this style before a

vendor has provided support for it.

2: Making & Using Objects

The libraries that have been inherited from C are still available with

the traditional `.h' extension. However, you can also use them with

the more modern C++ include style by prepending a "c" before the

name. Thus:

#include <stdio.h>

#include <stdlib.h>

become:

#include <cstdio>

#include <cstdlib>

And so on, for all the Standard C headers. This provides a nice

distinction to the reader indicating when you're using C versus

C++ libraries.

The effect of the new include format is not identical to the old:

using the .h gives you the older, non-template version, and

omitting the .h gives you the new templatized version. You'll

usually have problems if you try to intermix the two forms in a

single program.

Linking

The linker collects object modules (which often use file name

extensions like .o or .obj), generated by the compiler, into an

executable program the operating system can load and run. It is the

last phase of the compilation process.

Linker characteristics vary from system to system. In general, you

just tell the linker the names of the object modules and libraries you

want linked together, and the name of the executable, and it goes to

work. Some systems require you to invoke the linker yourself. With

most C++ packages you invoke the linker through the C++

compiler. In many situations, the linker is invoked for you

invisibly.

Thinking in C++

Some older linkers won't search object files and libraries more than

once, and they search through the list you give them from left to

right. This means that the order of object files and libraries can be

important. If you have a mysterious problem that doesn't show up

until link time, one possibility is the order in which the files are

given to the linker.

Using libraries

Now that you know the basic terminology, you can understand

how to use a library. To use a library:

Include the library's header file.

Use the functions and variables in the library.

Link the library into the executable program.

These steps also apply when the object modules aren't combined

into a library. Including a header file and linking the object

modules are the basic steps for separate compilation in both C and

C++.

How the linker searches a library

When you make an external reference to a function or variable in C

or C++, the linker, upon encountering this reference, can do one of

two things. If it has not already encountered the definition for the

function or variable, it adds the identifier to its list of "unresolved

references." If the linker has already encountered the definition, the

reference is resolved.

If the linker cannot find the definition in the list of object modules,

it searches the libraries. Libraries have some sort of indexing so the

linker doesn't need to look through all the object modules in the

library it just looks in the index. When the linker finds a definition

in a library, the entire object module, not just the function

definition, is linked into the executable program. Note that the

whole library isn't linked, just the object module in the library that

2: Making & Using Objects

contains the definition you want (otherwise programs would be

unnecessarily large). If you want to minimize executable program

size, you might consider putting a single function in each source

code file when you build your own libraries. This requires more

editing3, but it can be helpful to the user.

Because the linker searches files in the order you give them, you

can pre-empt the use of a library function by inserting a file with

your own function, using the same function name, into the list

before the library name appears. Since the linker will resolve any

references to this function by using your function before it searches

the library, your function is used instead of the library function.

Note that this can also be a bug, and the kind of thing C++

namespaces prevent.

Secret additions

When a C or C++ executable program is created, certain items are

secretly linked in. One of these is the startup module, which

contains initialization routines that must be run any time a C or

C++ program begins to execute. These routines set up the stack and

initialize certain variables in the program.

The linker always searches the standard library for the compiled

versions of any "standard" functions called in the program.

Because the standard library is always searched, you can use

anything in that library by simply including the appropriate header

file in your program; you don't have to tell it to search the standard

library. The iostream functions, for example, are in the Standard

C++ library. To use them, you just include the <iostream>header

file.

If you are using an add-on library, you must explicitly add the

library name to the list of files handed to the linker.

3 I would recommend using Perl or Python to automate this task as part of your

library-packaging process (see www.Perl.org or www.Python.org).

Thinking in C++

Using plain C libraries

Just because you are writing code in C++, you are not prevented

from using C library functions. In fact, the entire C library is

included by default into Standard C++. There has been a

tremendous amount of work done for you in these functions, so

they can save you a lot of time.

This book will use Standard C++ (and thus also Standard C) library

functions when convenient, but only standard library functions will

be used, to ensure the portability of programs. In the few cases in

which library functions must be used that are not in the C++

standard, all attempts will be made to use POSIX-compliant

functions. POSIX is a standard based on a Unix standardization

effort that includes functions that go beyond the scope of the C++

library. You can generally expect to find POSIX functions on Unix

(in particular, Linux) platforms, and often under DOS/Windows.

For example, if you're using multithreading you are better off using

the POSIX thread library because your code will then be easier to

understand, port and maintain (and the POSIX thread library will

usually just use the underlying thread facilities of the operating

system, if these are provided).

Your first C++ program

You now know almost enough of the basics to create and compile a

program. The program will use the Standard C++ iostream classes.

These read from and write to files and "standard" input and output

(which normally comes from and goes to the console, but may be

redirected to files or devices). In this simple program, a stream

object will be used to print a message on the screen.

Using the iostreams class

To declare the functions and external data in the iostreams class,

include the header file with the statement

#include <iostream>

2: Making & Using Objects

The first program uses the concept of standard output, which

means "a general-purpose place to send output." You will see other

examples using standard output in different ways, but here it will

just go to the console. The iostream package automatically defines a

variable (an object) called cout that accepts all data bound for

standard output.

To send data to standard output, you use the operator <<. C

programmers know this operator as the "bitwise left shift," which

will be described in the next chapter. Suffice it to say that a bitwise

left shift has nothing to do with output. However, C++ allows

operators to be overloaded. When you overload an operator, you

give it a new meaning when that operator is used with an object of

a particular type. With iostream objects, the operator << means

"send to." For example:

cout << "howdy!";

sends the string "howdy!" to the object called cout (which is short

for "console output").

That's enough operator overloading to get you started. Chapter 12

covers operator overloading in detail.

Namespaces

As mentioned in Chapter 1, one of the problems encountered in the

C language is that you "run out of names" for functions and

identifiers when your programs reach a certain size. Of course, you

don't really run out of names; it does, however, become harder to

think of new ones after awhile. More importantly, when a program

reaches a certain size it's typically broken up into pieces, each of

which is built and maintained by a different person or group. Since

C effectively has a single arena where all the identifier and function

names live, this means that all the developers must be careful not to

accidentally use the same names in situations where they can

100

Thinking in C++

conflict. This rapidly becomes tedious, time-wasting, and,

ultimately, expensive.

Standard C++ has a mechanism to prevent this collision: the

namespacekeyword. Each set of C++ definitions in a library or

program is "wrapped" in a namespace, and if some other definition

has an identical name, but is in a different namespace, then there is

no collision.

Namespaces are a convenient and helpful tool, but their presence

means that you must be aware of them before you can write any

programs. If you simply include a header file and use some

functions or objects from that header, you'll probably get strange-

sounding errors when you try to compile the program, to the effect

that the compiler cannot find any of the declarations for the items

that you just included in the header file! After you see this message

a few times you'll become familiar with its meaning (which is "You

included the header file but all the declarations are within a

namespace and you didn't tell the compiler that you wanted to use

the declarations in that namespace").

There's a keyword that allows you to say "I want to use the

declarations and/or definitions in this namespace." This keyword,

appropriately enough, is using. All of the Standard C++ libraries

are wrapped in a single namespace, which is std (for "standard").

As this book uses the standard libraries almost exclusively, you'll

see the following using directive in almost every program:

using namespace std;

This means that you want to expose all the elements from the

namespace called std. After this statement, you don't have to worry

that your particular library component is inside a namespace, since

the using directive makes that namespace available throughout the

file where the using directive was written.

2: Making & Using Objects

101

Exposing all the elements from a namespace after someone has

gone to the trouble to hide them may seem a bit counterproductive,

and in fact you should be careful about thoughtlessly doing this (as

you'll learn later in the book). However, the using directive

exposes only those names for the current file, so it is not quite as

drastic as it first sounds. (But think twice about doing it in a header

file that is reckless.)

There's a relationship between namespaces and the way header

files are included. Before the modern header file inclusion was

standardized (without the trailing `.h', as in <iostream> the

typical way to include a header file was with the `.h', such as

<iostream.h> At that time, namespaces were not part of the

language either. So to provide backward compatibility with

existing code, if you say

#include <iostream.h>

it means

#include <iostream>

using namespace std;

However, in this book the standard include format will be used

(without the `.h') and so the using directive must be explicit.

For now, that's all you need to know about namespaces, but in

Chapter 10 the subject is covered much more thoroughly.

Fundamentals of program structure

A C or C++ program is a collection of variables, function

definitions, and function calls. When the program starts, it executes

initialization code and calls a special function, "main( )." You put

the primary code for the program here.

As mentioned earlier, a function definition consists of a return type

(which must be specified in C++), a function name, an argument

102

Thinking in C++

list in parentheses, and the function code contained in braces. Here

is a sample function definition:

int function() {

// Function code here (this is a comment)

}

The function above has an empty argument list and a body that

contains only a comment.

There can be many sets of braces within a function definition, but

there must always be at least one set surrounding the function

body. Since main( ) is a function, it must follow these rules. In C++,

main( ) always has return type of int.

C and C++ are free form languages. With few exceptions, the

compiler ignores newlines and white space, so it must have some

way to determine the end of a statement. Statements are delimited

by semicolons.

C comments start with /* and end with */. They can include

newlines. C++ uses C-style comments and has an additional type of

comment: //. The // starts a comment that terminates with a

newline. It is more convenient than /* */ for one-line comments, and

is used extensively in this book.

"Hello, world!"

And now, finally, the first program:

//: C02:Hello.cpp

// Saying Hello with C++

#include <iostream> // Stream declarations

using namespace std;

int main() {

cout << "Hello, World! I am "

<< 8 << " Today!" << endl;

} ///:~

2: Making & Using Objects

103

The cout object is handed a series of arguments via the `<<'

operators. It prints out these arguments in left-to-right order. The

special iostream function endl outputs the line and a newline. With

iostreams, you can string together a series of arguments like this,

which makes the class easy to use.

In C, text inside double quotes is traditionally called a "string."

However, the Standard C++ library has a powerful class called

string for manipulating text, and so I shall use the more precise

term character array for text inside double quotes.

The compiler creates storage for character arrays and stores the

ASCII equivalent for each character in this storage. The compiler

automatically terminates this array of characters with an extra piece

of storage containing the value 0 to indicate the end of the character

array.

Inside a character array, you can insert special characters by using

escape sequences. These consist of a backslash (\) followed by a

special code. For example \n means newline. Your compiler

manual or local C guide gives a complete set of escape sequences;

others include \t (tab), \\ (backslash), and \b (backspace).

Notice that the statement can continue over multiple lines, and that

the entire statement terminates with a semicolon

Character array arguments and constant numbers are mixed

together in the above cout statement. Because the operator << is

overloaded with a variety of meanings when used with cout, you

can send cout a variety of different arguments and it will "figure

out what to do with the message."

Throughout this book you'll notice that the first line of each file will

be a comment that starts with the characters that start a comment

(typically //), followed by a colon, and the last line of the listing will

end with a comment followed by `/:~'. This is a technique I use to

allow easy extraction of information from code files (the program

104

Thinking in C++

to do this can be found in volume two of this book, at

). The first line also has the name and location

of the file, so it can be referred to in text and in other files, and so

you can easily locate it in the source code for this book (which is

downloadable from ).

Running the compiler

After downloading and unpacking the book's source code, find the

program in the subdirectory CO2. Invoke the compiler with

Hello.cppas the argument. For simple, one-file programs like this

one, most compilers will take you all the way through the process.

For example, to use the GNU C++ compiler (which is freely

available on the Internet), you write:

g++ Hello.cpp

Other compilers will have a similar syntax; consult your compiler's

documentation for details.

More about iostreams

So far you have seen only the most rudimentary aspect of the

iostreams class. The output formatting available with iostreams

also includes features such as number formatting in decimal, octal,

and hexadecimal. Here's another example of the use of iostreams:

//: C02:Stream2.cpp

// More streams features

#include <iostream>

using namespace std;

int main() {

// Specifying formats with manipulators:

cout << "a number in decimal: "

<< dec << 15 << endl;

cout << "in octal: " << oct << 15 << endl;

cout << "in hex: " << hex << 15 << endl;

cout << "a floating-point number: "

2: Making & Using Objects

105

<< 3.14159 << endl;

cout << "non-printing char (escape): "

<< char(27) << endl;

} ///:~

This example shows the iostreams class printing numbers in

decimal, octal, and hexadecimal using iostream manipulators (which

don't print anything, but change the state of the output stream).

The formatting of floating-point numbers is determined

automatically by the compiler. In addition, any character can be

sent to a stream object using a cast to a char (a char is a data type

that holds single characters). This cast looks like a function call:

char( ), along with the character's ASCII value. In the program

above, the char(27)sends an "escape" to cout.

Character array concatenation

An important feature of the C preprocessor is character array

concatenation. This feature is used in some of the examples in this

book. If two quoted character arrays are adjacent, and no

punctuation is between them, the compiler will paste the character

arrays together into a single character array. This is particularly

useful when code listings have width restrictions:

//: C02:Concat.cpp

// Character array Concatenation

#include <iostream>

using namespace std;

int main() {

cout << "This is far too long to put on a "

"single line but it can be broken up with "

"no ill effects\nas long as there is no "

"punctuation separating adjacent character "

"arrays.\n";

} ///:~

At first, the code above can look like an error because there's no

familiar semicolon at the end of each line. Remember that C and

C++ are free-form languages, and although you'll usually see a

106

Thinking in C++

semicolon at the end of each line, the actual requirement is for a

semicolon at the end of each statement, and it's possible for a

statement to continue over several lines.

Reading input

The iostreams classes provide the ability to read input. The object

used for standard input is cin (for "console input"). cin normally

expects input from the console, but this input can be redirected

from other sources. An example of redirection is shown later in this

chapter.

The iostreams operator used with cin is >>. This operator waits for

the same kind of input as its argument. For example, if you give it

an integer argument, it waits for an integer from the console. Here's

an example:

//: C02:Numconv.cpp

// Converts decimal to octal and hex

#include <iostream>

using namespace std;

int main() {

int number;

cout << "Enter

a decimal number: ";

cin >> number;

cout << "value

in octal = 0"

<< oct <<

number << endl;

cout << "value

in hex = 0x"

<< hex <<

number << endl;

} ///:~

This program converts a number typed in by the user into octal and

hexadecimal representations.

Calling other programs

While the typical way to use a program that reads from standard

input and writes to standard output is within a Unix shell script or

DOS batch file, any program can be called from inside a C or C++

2: Making & Using Objects

107

program using the Standard C system( )function, which is

declared in the header file <cstdlib>

//: C02:CallHello.cpp

// Call another program

#include <cstdlib> // Declare "system()"

using namespace std;

int main() {

system("Hello");

} ///:~

To use the system( )function, you give it a character array that you

would normally type at the operating system command prompt.

This can also include command-line arguments, and the character

array can be one that you fabricate at run time (instead of just using

a static character array as shown above). The command executes

and control returns to the program.

This program shows you how easy it is to use plain C library

functions in C++; just include the header file and call the function.

This upward compatibility from C to C++ is a big advantage if you

are learning the language starting from a background in C.

Introducing strings

While a character array can be fairly useful, it is quite limited. It's

simply a group of characters in memory, but if you want to do

anything with it you must manage all the little details. For example,

the size of a quoted character array is fixed at compile time. If you

have a character array and you want to add some more characters

to it, you'll need to understand quite a lot (including dynamic

memory management, character array copying, and concatenation)

before you can get your wish. This is exactly the kind of thing we'd

like to have an object do for us.

The Standard C++ string class is designed to take care of (and hide)

all the low-level manipulations of character arrays that were

108

Thinking in C++

previously required of the C programmer. These manipulations

have been a constant source of time-wasting and errors since the

inception of the C language. So, although an entire chapter is

devoted to the string class in Volume 2 of this book, the string is so

important and it makes life so much easier that it will be

introduced here and used in much of the early part of the book.

To use strings you include the C++ header file <string> The string

class is in the namespace std so a using directive is necessary.

Because of operator overloading, the syntax for using strings is

quite intuitive:

//: C02:HelloStrings.cpp

// The basics of the Standard C++ string class

#include <string>

#include <iostream>

using namespace std;

int main() {

string s1, s2; // Empty strings

string s3 = "Hello, World."; // Initialized

string s4("I am"); // Also initialized

s2 = "Today"; // Assigning to a string

s1 = s3 + " " + s4; // Combining strings

s1 += " 8 "; // Appending to a string

cout << s1 + s2 + "!" << endl;

} ///:~

The first two strings, s1 and s2, start out empty, while s3 and s4

show two equivalent ways to initialize string objects from character

arrays (you can just as easily initialize string objects from other

string objects).

You can assign to any string object using `='. This replaces the

previous contents of the string with whatever is on the right-hand

side, and you don't have to worry about what happens to the

previous contents that's handled automatically for you. To

combine strings you simply use the `+' operator, which also allows

you to combine character arrays with strings. If you want to

append either a string or a character array to another string, you

2: Making & Using Objects

109

can use the operator `+='. Finally, note that iostreams already know

what to do with strings, so you can just send a string (or an

expression that produces a string, which happens with s1 + s2 +

"!") directly to cout in order to print it.

Reading and writing files

In C, the process of opening and manipulating files requires a lot of

language background to prepare you for the complexity of the

operations. However, the C++ iostream library provides a simple

way to manipulate files, and so this functionality can be introduced

much earlier than it would be in C.

To open files for reading and writing, you must include <fstream>

Although this will automatically include <iostream> it's generally

prudent to explicitly include <iostream>if you're planning to use

cin, cout, etc.

To open a file for reading, you create an ifstreamobject, which then

behaves like cin. To open a file for writing, you create an ofstream

object, which then behaves like cout. Once you've opened the file,

you can read from it or write to it just as you would with any other

iostream object. It's that simple (which is, of course, the whole

point).

One of the most useful functions in the iostream library is

getline( ) which allows you to read one line (terminated by a

newline) into a string object4. The first argument is the ifstream

object you're reading from and the second argument is the string

object. When the function call is finished, the string object will

contain the line.

4 There are actually a number of variants of getline( ) which will be discussed

thoroughly in the iostreams chapter in Volume 2.

110

Thinking in C++

Here's a simple example, which copies the contents of one file into

another:

//: C02:Scopy.cpp

// Copy one file to another, a line at a time

#include <string>

#include <fstream>

using namespace std;

int main() {

ifstream in("Scopy.cpp"); // Open for reading

ofstream out("Scopy2.cpp"); // Open for writing

string s;

while(getline(in, s)) // Discards newline char

out << s << "\n"; // ... must add it back

} ///:~

To open the files, you just hand the ifstreamand ofstreamobjects

the file names you want to create, as seen above.

There is a new concept introduced here, which is the while loop.

Although this will be explained in detail in the next chapter, the

basic idea is that the expression in parentheses following the while

controls the execution of the subsequent statement (which can also

be multiple statements, wrapped inside curly braces). As long as

the expression in parentheses (in this case, getline(in, s) produces

)

a "true" result, then the statement controlled by the while will

continue to execute. It turns out that getline( )will return a value

that can be interpreted as "true" if another line has been read

successfully, and "false" upon reaching the end of the input. Thus,

the above while loop reads every line in the input file and sends

each line to the output file.

getline( )reads in the characters of each line until it discovers a

newline (the termination character can be changed, but that won't

be an issue until the iostreams chapter in Volume 2). However, it

discards the newline and doesn't store it in the resulting string

object. Thus, if we want the copied file to look just like the source

file, we must add the newline back in, as shown.

2: Making & Using Objects

111

Another interesting example is to copy the entire file into a single

string object:

//: C02:FillString.cpp

// Read an entire file into a single string

#include <string>

#include <iostream>

#include <fstream>

using namespace std;

int main() {

ifstream in("FillString.cpp");

string s, line;

while(getline(in, line))

s += line + "\n";

cout << s;

} ///:~

Because of the dynamic nature of strings, you don't have to worry

about how much storage to allocate for a string; you can just keep

adding things and the string will keep expanding to hold whatever

you put into it.

One of the nice things about putting an entire file into a string is

that the string class has many functions for searching and

manipulation that would then allow you to modify the file as a

single string. However, this has its limitations. For one thing, it is

often convenient to treat a file as a collection of lines instead of just

a big blob of text. For example, if you want to add line numbering

it's much easier if you have each line as a separate string object. To

accomplish this, we'll need another approach.

Introducing vector

With strings, we can fill up a string object without knowing how

much storage we're going to need. The problem with reading lines

from a file into individual string objects is that you don't know up

front how many strings you're going to need you only know after

you've read the entire file. To solve this problem, we need some

112

Thinking in C++

sort of holder that will automatically expand to contain as many

string objects as we care to put into it.

In fact, why limit ourselves to holding string objects? It turns out

that this kind of problem not knowing how many of something

you have while you're writing a program happens a lot. And this

"container" object sounds like it would be more useful if it would

hold any kind of object at all! Fortunately, the Standard C++ Library

has a ready-made solution: the standard container classes. The

container classes are one of the real powerhouses of Standard C++.

There is often a bit of confusion between the containers and

algorithms in the Standard C++ Library, and the entity known as

the STL. The Standard Template Library was the name Alex

Stepanov (who was working at Hewlett-Packard at the time) used

when he presented his library to the C++ Standards Committee at

the meeting in San Diego, California in Spring 1994. The name

stuck, especially after HP decided to make it available for public

downloads. Meanwhile, the committee integrated it into the

Standard C++ Library, making a large number of changes. STL's

development continues at Silicon Graphics (SGI; see

http://www.sgi.com/Technology/STL). The SGI STL diverges from the

Standard C++ Library on many subtle points. So although it's a

popular misconception, the C++ Standard does not "include" the

STL. It can be a bit confusing since the containers and algorithms in

the Standard C++ Library have the same root (and usually the same

names) as the SGI STL. In this book, I will say "The Standard C++

Library" or "The Standard Library containers," or something

similar and will avoid the term "STL."

Even though the implementation of the Standard C++ Library

containers and algorithms uses some advanced concepts and the

full coverage takes two large chapters in Volume 2 of this book, this

library can also be potent without knowing a lot about it. It's so

useful that the most basic of the standard containers, the vector, is

introduced in this early chapter and used throughout the book.

2: Making & Using Objects

113

You'll find that you can do a tremendous amount just by using the

basics of vector and not worrying about the underlying

implementation (again, an important goal of OOP). Since you'll

learn much more about this and the other containers when you

reach the Standard Library chapters in Volume 2, it seems

forgivable if the programs that use vector in the early portion of the

book aren't exactly what an experienced C++ programmer would

do. You'll find that in most cases, the usage shown here is

adequate.

The vector class is a template, which means that it can be efficiently

applied to different types. That is, we can create a vector of shapes,

a vector of cats, a vector of strings, etc. Basically, with a template

you can create a "class of anything." To tell the compiler what it is

that the class will work with (in this case, what the vector will

hold), you put the name of the desired type in "angle brackets,"

which means `<' and `>'. So a vector of string would be denoted

vector<string> When you do this, you end up with a customized

vector that will hold only string objects, and you'll get an error

message from the compiler if you try to put anything else into it.

Since vector expresses the concept of a "container," there must be a

way to put things into the container and get things back out of the

container. To add a brand-new element on the end of a vector, you

use the member function push_back( ).(Remember that, since it's a

member function, you use a `.' to call it for a particular object.) The

reason the name of this member function might seem a bit verbose

push_back( )instead of something simpler like "put" is because

there are other containers and other member functions for putting

new elements into containers. For example, there is an insert( )

member function to put something in the middle of a container.

vector supports this but its use is more complicated and we won't

need to explore it until Volume 2 of the book. There's also a

push_front( )(not part of vector) to put things at the beginning.

There are many more member functions in vector and many more

114

Thinking in C++

containers in the Standard C++ Library, but you'll be surprised at

how much you can do just knowing about a few simple features.

So you can put new elements into a vector with push_back( ) but

how do you get these elements back out again? This solution is

more clever and elegant operator overloading is used to make the

vector look like an array. The array (which will be described more

fully in the next chapter) is a data type that is available in virtually

every programming language so you should already be somewhat

familiar with it. Arrays are aggregates, which mean they consist of a

number of elements clumped together. The distinguishing

characteristic of an array is that these elements are the same size

and are arranged to be one right after the other. Most importantly,

these elements can be selected by "indexing," which means you can

say "I want element number n" and that element will be produced,

usually quickly. Although there are exceptions in programming

languages, the indexing is normally achieved using square

brackets, so if you have an array a and you want to produce

element five, you say a[4] (note that indexing always starts at zero).

This very compact and powerful indexing notation is incorporated

into the vector using operator overloading, just like `<<' and `>>'

were incorporated into iostreams. Again, you don't need to know

how the overloading was implemented that's saved for a later

chapter but it's helpful if you're aware that there's some magic

going on under the covers in order to make the [ ] work with

vector.

With that in mind, you can now see a program that uses vector. To

use a vector, you include the header file <vector>

//: C02:Fillvector.cpp

// Copy an entire file into a vector of string

#include <string>

#include <iostream>

#include <fstream>

#include <vector>

using namespace std;

2: Making & Using Objects

115

int main() {

vector<string> v;

ifstream in("Fillvector.cpp");

string line;

while(getline(in, line))

v.push_back(line); // Add the line to the end

// Add line numbers:

for(int i = 0; i < v.size(); i++)

cout << i << ": " << v[i] << endl;

} ///:~

Much of this program is similar to the previous one; a file is opened

and lines are read into string objects one at a time. However, these

string objects are pushed onto the back of the vector v Once the

while loop completes, the entire file is resident in memory, inside

The next statement in the program is called a for loop. It is similar

to a while loop except that it adds some extra control. After the for,

there is a "control expression" inside of parentheses, just like the

while loop. However, this control expression is in three parts: a

part which initializes, one that tests to see if we should exit the

loop, and one that changes something, typically to step through a

sequence of items. This program shows the for loop in the way

you'll see it most commonly used: the initialization part int i = 0

creates an integer i to use as a loop counter and gives it an initial

value of zero. The testing portion says that to stay in the loop, i

should be less than the number of elements in the vector v (This is

produced using the member function size( ),which I just sort of

slipped in here, but you must admit it has a fairly obvious

meaning.) The final portion uses a shorthand for C and C++, the

"auto-increment" operator, to add one to the value of i. Effectively,

i++ says "get the value of i, add one to it, and put the result back

into i. Thus, the total effect of the for loop is to take a variable i and

march it through the values from zero to one less than the size of

the vector. For each value of i, the cout statement is executed and

this builds a line that consists of the value of i (magically converted

to a character array by cout), a colon and a space, the line from the

116

Thinking in C++

file, and a newline provided by endl. When you compile and run it

you'll see the effect is to add line numbers to the file.

Because of the way that the `>>' operator works with iostreams,

you can easily modify the program above so that it breaks up the

input into whitespace-separated words instead of lines:

//: C02:GetWords.cpp

// Break a file into whitespace-separated words

#include <string>

#include <iostream>

#include <fstream>

#include <vector>

using namespace std;

int main() {

vector<string> words;

ifstream in("GetWords.cpp");

string word;

while(in >> word)

words.push_back(word);

for(int i = 0; i < words.size(); i++)

cout << words[i] << endl;

} ///:~

The expression

while(in >> word)

is what gets the input one "word" at a time, and when this

expression evaluates to "false" it means the end of the file has been

reached. Of course, delimiting words by whitespace is quite crude,

but it makes for a simple example. Later in the book you'll see more

sophisticated examples that let you break up input just about any

way you'd like.

To demonstrate how easy it is to use a vector with any type, here's

an example that creates a vector<int>

//: C02:Intvector.cpp

// Creating a vector that holds integers

#include <iostream>

2: Making & Using Objects

117

#include <vector>

using namespace std;

int main() {

vector<int> v;

for(int i = 0; i < 10; i++)

v.push_back(i);

for(int i = 0; i < v.size(); i++)

cout << v[i] << ", ";

cout << endl;

for(int i = 0; i < v.size(); i++)

v[i] = v[i] * 10; // Assignment

for(int i = 0; i < v.size(); i++)

cout << v[i] << ", ";

cout << endl;

} ///:~

To create a vector that holds a different type, you just put that type

in as the template argument (the argument in angle brackets).

Templates and well-designed template libraries are intended to be

exactly this easy to use.

This example goes on to demonstrate another essential feature of

vector. In the expression

v[i] = v[i] * 10;

you can see that the vector is not limited to only putting things in

and getting things out. You also have the ability to assign (and thus

to change) to any element of a vector, also through the use of the

square-brackets indexing operator. This means that vector is a

general-purpose, flexible "scratchpad" for working with collections

of objects, and we will definitely make use of it in coming chapters.

Summary

The intent of this chapter is to show you how easy object-oriented

programming can be if someone else has gone to the work of

defining the objects for you. In that case, you include a header file,

create the objects, and send messages to them. If the types you are

118

Thinking in C++

using are powerful and well-designed, then you won't have to do

much work and your resulting program will also be powerful.

In the process of showing the ease of OOP when using library

classes, this chapter also introduced some of the most basic and

useful types in the Standard C++ library: the family of iostreams (in

particular, those that read from and write to the console and files),

the string class, and the vector template. You've seen how

straightforward it is to use these and can now probably imagine

many things you can accomplish with them, but there's actually a

lot more that they're capable of5. Even though we'll only be using a

limited subset of the functionality of these tools in the early part of

the book, they nonetheless provide a large step up from the

primitiveness of learning a low-level language like C. and while

learning the low-level aspects of C is educational, it's also time

consuming. In the end, you'll be much more productive if you've

got objects to manage the low-level issues. After all, the whole point

of OOP is to hide the details so you can "paint with a bigger

brush."

However, as high-level as OOP tries to be, there are some

fundamental aspects of C that you can't avoid knowing, and these

will be covered in the next chapter.

Exercises

Solutions to selected exercises can be found in the electronic document The Thinking in C++ Annotated

Solution Guide, available for a small fee from http://

Modify Hello.cppso that it prints out your name and age

(or shoe size, or your dog's age, if that makes you feel

better). Compile and run the program.

5 If you're particularly eager to see all the things that can be done with these and

other Standard library components, see Volume 2 of this book at

, and also www.dinkumware.com.

2: Making & Using Objects

119

Using Stream2.cppand Numconv.cppas guidelines,

create a program that asks for the radius of a circle and

prints the area of that circle. You can just use the `*'

operator to square the radius. Do not try to print out the

value as octal or hex (these only work with integral

types).

Create a program that opens a file and counts the

whitespace-separated words in that file.

Create a program that counts the occurrence of a

particular word in a file (use the string class' operator

`==' to find the word).

Change Fillvector.cppso that it prints the lines

(backwards) from last to first.

Change Fillvector.cppso that it concatenates all the

elements in the vector into a single string before printing

it out, but don't try to add line numbering.

Display a file a line at a time, waiting for the user to press

the "Enter" key after each line.

Create a vector<float>and put 25 floating-point numbers

into it using a for loop. Display the vector.

Create three vector<float>objects and fill the first two as

in the previous exercise. Write a for loop that adds each

corresponding element in the first two vectors and puts

the result in the corresponding element of the third

vector. Display all three vectors.

10.

Create a vector<float>and put 25 numbers into it as in

the previous exercises. Now square each number and put

the result back into the same location in the vector.

Display the vector before and after the multiplication.

120

Thinking in C++

Table of Contents:
