15: Polymorphism &
Virtual Functions
Polymorphism (implemented in C++ with virtual
functions) is the third essential feature of an object-
oriented programming language, after data abstraction
and inheritance.
659
It provides another dimension of separation of interface from
implementation, to decouple what from how. Polymorphism allows
improved code organization and readability as well as the creation
of extensible programs that can be "grown" not only during the
original creation of the project, but also when new features are
desired.
Encapsulation creates new data types by combining characteristics
and behaviors. Access control separates the interface from the
implementation by making the details private. This kind of
mechanical organization makes ready sense to someone with a
procedural programming background. But virtual functions deal
with decoupling in terms of types. In Chapter 14, you saw how
inheritance allows the treatment of an object as its own type or its
base type. This ability is critical because it allows many types
(derived from the same base type) to be treated as if they were one
type, and a single piece of code to work on all those different types
equally. The virtual function allows one type to express its
distinction from another, similar type, as long as they're both
derived from the same base type. This distinction is expressed
through differences in behavior of the functions that you can call
through the base class.
In this chapter, you'll learn about virtual functions, starting from
the basics with simple examples that strip away everything but the
"virtualness" of the program.
Evolution of C++ programmers
C programmers seem to acquire C++ in three steps. First, as simply
a "better C," because C++ forces you to declare all functions before
using them and is much pickier about how variables are used. You
can often find the errors in a C program simply by compiling it
with a C++ compiler.
660
Thinking in C++
The second step is "object-based" C++. This means that you easily
see the code organization benefits of grouping a data structure
together with the functions that act upon it, the value of
constructors and destructors, and perhaps some simple inheritance.
Most programmers who have been working with C for a while
quickly see the usefulness of this because, whenever they create a
library, this is exactly what they try to do. With C++, you have the
aid of the compiler.
You can get stuck at the object-based level because you can quickly
get there and you get a lot of benefit without much mental effort.
It's also easy to feel like you're creating data types ­ you make
classes and objects, you send messages to those objects, and
everything is nice and neat.
But don't be fooled. If you stop here, you're missing out on the
greatest part of the language, which is the jump to true object-
oriented programming. You can do this only with virtual functions.
Virtual functions enhance the concept of type instead of just
encapsulating code inside structures and behind walls, so they are
without a doubt the most difficult concept for the new C++
programmer to fathom. However, they're also the turning point in
the understanding of object-oriented programming. If you don't
use virtual functions, you don't understand OOP yet.
Because the virtual function is intimately bound with the concept of
type, and type is at the core of object-oriented programming, there
is no analog to the virtual function in a traditional procedural
language. As a procedural programmer, you have no referent with
which to think about virtual functions, as you do with almost every
other feature in the language. Features in a procedural language
can be understood on an algorithmic level, but virtual functions can
be understood only from a design viewpoint.
15: Polymorphism & Virtual Functions
661
Upcasting
In Chapter 14 you saw how an object can be used as its own type or
as an object of its base type. In addition, it can be manipulated
through an address of the base type. Taking the address of an
object (either a pointer or a reference) and treating it as the address
of the base type is called upcasting because of the way inheritance
trees are drawn with the base class at the top.
You also saw a problem arise, which is embodied in the following
code:
//: C15:Instrument2.cpp
// Inheritance & upcasting
#include <iostream>
using namespace std;
enum note { middleC, Csharp, Eflat }; // Etc.
class Instrument {
public:
void play(note) const {
cout << "Instrument::play" << endl;
}
};
// Wind objects are Instruments
// because they have the same interface:
class Wind : public Instrument {
public:
// Redefine interface function:
void play(note) const {
cout << "Wind::play" << endl;
}
};
void tune(Instrument& i) {
// ...
i.play(middleC);
}
int main() {
Wind flute;
tune(flute); // Upcasting
662
Thinking in C++
} ///:~
The function tune( ) accepts (by reference) an Instrument but also
,
without complaint anything derived from Instrument In main( ),
.
you can see this happening as a Wind object is passed to tune( ),
with no cast necessary. This is acceptable; the interface in
Instrumentmust exist in Wind, because Wind is publicly inherited
from Instrument Upcasting from Wind to Instrumentmay
.
"narrow" that interface, but never less than the full interface to
Instrument
.
The same arguments are true when dealing with pointers; the only
difference is that the user must explicitly take the addresses of
objects as they are passed into the function.
The problem
The problem with Instrument2.cppcan be seen by running the
program. The output is Instrument::playThis is clearly not the
.
desired output, because you happen to know that the object is
actually a Wind and not just an Instrument The call should
.
produce Wind::play For that matter, any object of a class derived
.
from Instrumentshould have its version of play( ) used, regardless
of the situation.
The behavior of Instrument2.cppis not surprising, given C's
approach to functions. To understand the issues, you need to be
aware of the concept of binding.
Function call binding
Connecting a function call to a function body is called binding.
When binding is performed before the program is run (by the
compiler and linker), it's called early binding. You may not have
heard the term before because it's never been an option with
procedural languages: C compilers have only one kind of function
call, and that's early binding.
15: Polymorphism & Virtual Functions
663
The problem in the program above is caused by early binding
because the compiler cannot know the correct function to call when
it has only an Instrumentaddress.
The solution is called late binding, which means the binding occurs
at runtime, based on the type of the object. Late binding is also
called dynamic binding or runtime binding. When a language
implements late binding, there must be some mechanism to
determine the type of the object at runtime and call the appropriate
member function. In the case of a compiled language, the compiler
still doesn't know the actual object type, but it inserts code that
finds out and calls the correct function body. The late-binding
mechanism varies from language to language, but you can imagine
that some sort of type information must be installed in the objects.
You'll see how this works later.
virtual functions
To cause late binding to occur for a particular function, C++
requires that you use the virtual keyword when declaring the
function in the base class. Late binding occurs only with virtual
functions, and only when you're using an address of the base class
where those virtual functions exist, although they may also be
defined in an earlier base class.
To create a member function as virtual, you simply precede the
declaration of the function with the keyword virtual. Only the
declaration needs the virtual keyword, not the definition. If a
function is declared as virtual in the base class, it is virtual in all the
derived classes. The redefinition of a virtual function in a derived
class is usually called overriding.
Notice that you are only required to declare a function virtual in
the base class. All derived-class functions that match the signature
of the base-class declaration will be called using the virtual
mechanism. You can use the virtual keyword in the derived-class
664
Thinking in C++
declarations (it does no harm to do so), but it is redundant and can
be confusing.
To get the desired behavior from Instrument2.cpp simply add the
,
virtual keyword in the base class before play( ):
//: C15:Instrument3.cpp
// Late binding with the virtual keyword
#include <iostream>
using namespace std;
enum note { middleC, Csharp, Cflat }; // Etc.
class Instrument {
public:
virtual void play(note) const {
cout << "Instrument::play" << endl;
}
};
// Wind objects are Instruments
// because they have the same interface:
class Wind : public Instrument {
public:
// Override interface function:
void play(note) const {
cout << "Wind::play" << endl;
}
};
void tune(Instrument& i) {
// ...
i.play(middleC);
}
int main() {
Wind flute;
tune(flute); // Upcasting
} ///:~
This file is identical to Instrument2.cppexcept for the addition of
the virtual keyword, and yet the behavior is significantly different:
Now the output is Wind::play
.
15: Polymorphism & Virtual Functions
665
Extensibility
With play( ) defined as virtual in the base class, you can add as
many new types as you want without changing the tune( )
function. In a well-designed OOP program, most or all of your
functions will follow the model of tune( ) and communicate only
with the base-class interface. Such a program is extensible because
you can add new functionality by inheriting new data types from
the common base class. The functions that manipulate the base-
class interface will not need to be changed at all to accommodate
the new classes.
Here's the instrument example with more virtual functions and a
number of new classes, all of which work correctly with the old,
unchanged tune( ) function:
//: C15:Instrument4.cpp
// Extensibility in OOP
#include <iostream>
using namespace std;
enum note { middleC, Csharp, Cflat }; // Etc.
class Instrument {
public:
virtual void play(note) const {
cout << "Instrument::play" << endl;
}
virtual char* what() const {
return "Instrument";
}
// Assume this will modify the object:
virtual void adjust(int) {}
};
class Wind : public Instrument {
public:
void play(note) const {
cout << "Wind::play" << endl;
}
char* what() const { return "Wind"; }
void adjust(int) {}
};
666
Thinking in C++
class Percussion : public Instrument {
public:
void play(note) const {
cout << "Percussion::play" << endl;
}
char* what() const { return "Percussion"; }
void adjust(int) {}
};
class Stringed : public Instrument {
public:
void play(note) const {
cout << "Stringed::play" << endl;
}
char* what() const { return "Stringed"; }
void adjust(int) {}
};
class Brass : public Wind {
public:
void play(note) const {
cout << "Brass::play" << endl;
}
char* what() const { return "Brass"; }
};
class Woodwind : public Wind {
public:
void play(note) const {
cout << "Woodwind::play" << endl;
}
char* what() const { return "Woodwind"; }
};
// Identical function from before:
void tune(Instrument& i) {
// ...
i.play(middleC);
}
// New function:
void f(Instrument& i) { i.adjust(1); }
// Upcasting during array initialization:
15: Polymorphism & Virtual Functions
667
Instrument* A[] = {
new Wind,
new Percussion,
new Stringed,
new Brass,
};
int main() {
Wind flute;
Percussion drum;
Stringed violin;
Brass flugelhorn;
Woodwind recorder;
tune(flute);
tune(drum);
tune(violin);
tune(flugelhorn);
tune(recorder);
f(flugelhorn);
} ///:~
You can see that another inheritance level has been added beneath
Wind, but the virtual mechanism works correctly no matter how
many levels there are. The adjust( )function is not overridden for
Brass and Woodwind When this happens, the "closest" definition
.
in the inheritance hierarchy is automatically used ­ the compiler
guarantees there's always some definition for a virtual function, so
you'll never end up with a call that doesn't bind to a function body.
(That would be disastrous.)
The array A[ ] contains pointers to the base class Instrument so
,
upcasting occurs during the process of array initialization. This
array and the function f( ) will be used in later discussions.
In the call to tune( ), upcasting is performed on each different type
of object, yet the desired behavior always takes place. This can be
described as "sending a message to an object and letting the object
worry about what to do with it." The virtual function is the lens to
use when you're trying to analyze a project: Where should the base
classes occur, and how might you want to extend the program?
668
Thinking in C++
.
However, even if you don't discover the proper base class
interfaces and virtual functions at the initial creation of the
program, you'll often discover them later, even much later, when
you set out to extend or otherwise maintain the program. This is
not an analysis or design error; it simply means you didn't or
couldn't know all the information the first time. Because of the tight
class modularization in C++, it isn't a large problem when this
occurs because changes you make in one part of a system tend not
to propagate to other parts of the system as they do in C.
How C++ implements late binding
How can late binding happen? All the work goes on behind the
scenes by the compiler, which installs the necessary late-binding
mechanism when you ask it to (you ask by creating virtual
functions). Because programmers often benefit from understanding
the mechanism of virtual functions in C++, this section will
elaborate on the way the compiler implements this mechanism.
The keyword virtual tells the compiler it should not perform early
binding. Instead, it should automatically install all the mechanisms
necessary to perform late binding. This means that if you call
play( ) for a Brass object through an address for the base-class
Instrument you'll get the proper function.
,
To accomplish this, the typical compiler1 creates a single table
(called the VTABLE) for each class that contains virtual functions.
The compiler places the addresses of the virtual functions for that
particular class in the VTABLE. In each class with virtual functions,
it secretly places a pointer, called the vpointer (abbreviated as
VPTR), which points to the VTABLE for that object. When you
make a virtual function call through a base-class pointer (that is,
1 Compilers may implement virtual behavior any way they want, but the way it's
described here is an almost universal approach.
15: Polymorphism & Virtual Functions
669
when you make a polymorphic call), the compiler quietly inserts
code to fetch the VPTR and look up the function address in the
VTABLE, thus calling the correct function and causing late binding
to take place.
All of this ­ setting up the VTABLE for each class, initializing the
VPTR, inserting the code for the virtual function call ­ happens
automatically, so you don't have to worry about it. With virtual
functions, the proper function gets called for an object, even if the
compiler cannot know the specific type of the object.
The following sections go into this process in more detail.
Storing type information
You can see that there is no explicit type information stored in any
of the classes. But the previous examples, and simple logic, tell you
that there must be some sort of type information stored in the
objects; otherwise the type could not be established at runtime. This
is true, but the type information is hidden. To see it, here's an
example to examine the sizes of classes that use virtual functions
compared with those that don't:
//: C15:Sizes.cpp
// Object sizes with/without virtual functions
#include <iostream>
using namespace std;
class NoVirtual {
int a;
public:
void x() const {}
int i() const { return 1; }
};
class OneVirtual {
int a;
public:
virtual void x() const {}
int i() const { return 1; }
670
Thinking in C++
.
};
class TwoVirtuals {
int a;
public:
virtual void x() const {}
virtual int i() const { return 1; }
};
int main() {
cout << "int: " << sizeof(int) << endl;
cout << "NoVirtual: "
<< sizeof(NoVirtual) << endl;
cout << "void* : " << sizeof(void*) << endl;
cout << "OneVirtual: "
<< sizeof(OneVirtual) << endl;
cout << "TwoVirtuals: "
<< sizeof(TwoVirtuals) << endl;
} ///:~
With no virtual functions, the size of the object is exactly what
you'd expect: the size of a single2 int. With a single virtual function
in OneVirtual the size of the object is the size of NoVirtualplus
,
the size of a void pointer. It turns out that the compiler inserts a
single pointer (the VPTR) into the structure if you have one or more
virtual functions. There is no size difference between OneVirtual
and TwoVirtuals That's because the VPTR points to a table of
.
function addresses. You need only one table because all the virtual
function addresses are contained in that single table.
This example required at least one data member. If there had been
no data members, the C++ compiler would have forced the objects
to be a nonzero size because each object must have a distinct
address. If you imagine indexing into an array of zero-sized objects,
you'll understand. A "dummy" member is inserted into objects that
would otherwise be zero-sized. When the type information is
inserted because of the virtual keyword, this takes the place of the
2 Some compilers might have size issues here but it will be rare.
15: Polymorphism & Virtual Functions
671
"dummy" member. Try commenting out the int a in all the classes
in the example above to see this.
Picturing virtual functions
To understand exactly what's going on when you use a virtual
function, it's helpful to visualize the activities going on behind the
curtain. Here's a drawing of the array of pointers A[ ] in
Instrument4.cpp
:
VTABLEs:
Objects:
&Wind::play
Wind object
Array of
&Wind::what
vptr
Instrument
&Wind::adjust
pointers A[ ]
&Percussion::play
Percussion object
&Percussion::what
vptr
&Percussion::adjust
Stringed object
&Stringed::play
vptr
&Stringed::what
&Stringed::adjust
Brass object
&Brass::play
vptr
&Brass::what
&Wind::adjust
The array of Instrumentpointers has no specific type information;
they each point to an object of type Instrument Wind, Percussion
.
,
Stringed and Brass all fit into this category because they are
,
derived from Instrument(and thus have the same interface as
Instrument and can respond to the same messages), so their
,
addresses can also be placed into the array. However, the compiler
doesn't know that they are anything more than Instrumentobjects,
so left to its own devices it would normally call the base-class
versions of all the functions. But in this case, all those functions
have been declared with the virtual keyword, so something
different happens.
672
Thinking in C++
Each time you create a class that contains virtual functions, or you
derive from a class that contains virtual functions, the compiler
creates a unique VTABLE for that class, seen on the right of the
diagram. In that table it places the addresses of all the functions
that are declared virtual in this class or in the base class. If you
don't override a function that was declared virtual in the base class,
the compiler uses the address of the base-class version in the
derived class. (You can see this in the adjust entry in the Brass
VTABLE.) Then it places the VPTR (discovered in Sizes.cpp into
)
the class. There is only one VPTR for each object when using simple
inheritance like this. The VPTR must be initialized to point to the
starting address of the appropriate VTABLE. (This happens in the
constructor, which you'll see later in more detail.)
Once the VPTR is initialized to the proper VTABLE, the object in
effect "knows" what type it is. But this self-knowledge is worthless
unless it is used at the point a virtual function is called.
When you call a virtual function through a base class address (the
situation when the compiler doesn't have all the information
necessary to perform early binding), something special happens.
Instead of performing a typical function call, which is simply an
assembly-language CALL to a particular address, the compiler
generates different code to perform the function call. Here's what a
call to adjust( )for a Brass object looks like, if made through an
Instrumentpointer (An Instrumentreference produces the same
result):
Brass VTABLE:
Instrument
pointer
[0]
&Brass::play
Brass object
[1]
&Brass::what
vptr
[2] &Wind::adjust
The compiler begins with the Instrumentpointer, which points to
the starting address of the object. All Instrumentobjects or objects
derived from Instrumenthave their VPTR in the same place (often
at the beginning of the object), so the compiler can pick the VPTR
15: Polymorphism & Virtual Functions
673
out of the object. The VPTR points to the starting address of the
VTABLE. All the VTABLE function addresses are laid out in the
same order, regardless of the specific type of the object. play( ) is
first, what( ) is second, and adjust( )is third. The compiler knows
that regardless of the specific object type, the adjust( )function is at
the location VPTR+2. Thus, instead of saying, "Call the function at
the absolute location Instrument::adjust (early binding; the wrong
"
action), it generates code that says, in effect, "Call the function at
VPTR+2." Because the fetching of the VPTR and the determination
of the actual function address occur at runtime, you get the desired
late binding. You send a message to the object, and the object
figures out what to do with it.
Under the hood
It can be helpful to see the assembly-language code generated by a
virtual function call, so you can see that late-binding is indeed
taking place. Here's the output from one compiler for the call
i.adjust(1);
inside the function f(Instrument& i)
:
push
1
push
si
mov
bx, word ptr [si]
call
word ptr [bx+4]
add
sp, 4
The arguments of a C++ function call, like a C function call, are
pushed on the stack from right to left (this order is required to
support C's variable argument lists), so the argument 1 is pushed
on the stack first. At this point in the function, the register si (part
of the Intel X86 processor architecture) contains the address of i.
This is also pushed on the stack because it is the starting address of
the object of interest. Remember that the starting address
corresponds to the value of this, and this is quietly pushed on the
stack as an argument before every member function call, so the
member function knows which particular object it is working on.
674
Thinking in C++
So you'll always see one more than the number of arguments
pushed on the stack before a member function call (except for static
member functions, which have no this).
Now the actual virtual function call must be performed. First, the
VPTR must be produced, so the VTABLE can be found. For this
compiler the VPTR is inserted at the beginning of the object, so the
contents of this correspond to the VPTR. The line
mov bx, word ptr [si]
fetches the word that si (that is, this) points to, which is the VPTR.
It places the VPTR into the register bx.
The VPTR contained in bx points to the starting address of the
VTABLE, but the function pointer to call isn't at location zero of the
VTABLE, but instead at location two (because it's the third function
in the list). For this memory model each function pointer is two
bytes long, so the compiler adds four to the VPTR to calculate
where the address of the proper function is. Note that this is a
constant value, established at compile time, so the only thing that
matters is that the function pointer at location number two is the
one for adjust( ) Fortunately, the compiler takes care of all the
.
bookkeeping for you and ensures that all the function pointers in
all the VTABLEs of a particular class hierarchy occur in the same
order, regardless of the order that you may override them in
derived classes.
Once the address of the proper function pointer in the VTABLE is
calculated, that function is called. So the address is fetched and
called all at once in the statement
call word ptr [bx+4]
Finally, the stack pointer is moved back up to clean off the
arguments that were pushed before the call. In C and C++
assembly code you'll often see the caller clean off the arguments
15: Polymorphism & Virtual Functions
675
but this may vary depending on processors and compiler
implementations.
Installing the vpointer
Because the VPTR determines the virtual function behavior of the
object, you can see how it's critical that the VPTR always be
pointing to the proper VTABLE. You don't ever want to be able to
make a call to a virtual function before the VPTR is properly
initialized. Of course, the place where initialization can be
guaranteed is in the constructor, but none of the Instrument
examples has a constructor.
This is where creation of the default constructor is essential. In the
Instrumentexamples, the compiler creates a default constructor
that does nothing except initialize the VPTR. This constructor, of
course, is automatically called for all Instrumentobjects before you
can do anything with them, so you know that it's always safe to call
virtual functions.
The implications of the automatic initialization of the VPTR inside
the constructor are discussed in a later section.
Objects are different
It's important to realize that upcasting deals only with addresses. If
the compiler has an object, it knows the exact type and therefore (in
C++) will not use late binding for any function calls ­ or at least, the
compiler doesn't need to use late binding. For efficiency's sake,
most compilers will perform early binding when they are making a
call to a virtual function for an object because they know the exact
type. Here's an example:
//: C15:Early.cpp
// Early binding & virtual functions
#include <iostream>
#include <string>
using namespace std;
676
Thinking in C++
class Pet {
public:
virtual string speak() const { return ""; }
};
class Dog : public Pet {
public:
string speak() const { return "Bark!"; }
};
int main() {
Dog ralph;
Pet* p1 = &ralph;
Pet& p2 = ralph;
Pet p3;
// Late binding for both:
cout << "p1->speak() = " << p1->speak() <<endl;
cout << "p2.speak() = " << p2.speak() << endl;
// Early binding (probably):
cout << "p3.speak() = " << p3.speak() << endl;
} ///:~
In p1­>speak( )and p2.speak( ) addresses are used, which means
,
the information is incomplete: p1 and p2 can represent the address
of a Pet or something derived from Pet, so the virtual mechanism
must be used. When calling p3.speak( )there's no ambiguity. The
compiler knows the exact type and that it's an object, so it can't
possibly be an object derived from Pet ­ it's exactly a Pet. Thus,
early binding is probably used. However, if the compiler doesn't
want to work so hard, it can still use late binding and the same
behavior will occur.
Why virtual functions?
At this point you may have a question: "If this technique is so
important, and if it makes the `right' function call all the time, why
is it an option? Why do I even need to know about it?"
15: Polymorphism & Virtual Functions
677
..
This is a good question, and the answer is part of the fundamental
philosophy of C++: "Because it's not quite as efficient." You can see
from the previous assembly-language output that instead of one
simple CALL to an absolute address, there are two ­ more
sophisticated ­ assembly instructions required to set up the virtual
function call. This requires both code space and execution time.
Some object-oriented languages have taken the approach that late
binding is so intrinsic to object-oriented programming that it
should always take place, that it should not be an option, and the
user shouldn't have to know about it. This is a design decision
when creating a language, and that particular path is appropriate
for many languages.3 However, C++ comes from the C heritage,
where efficiency is critical. After all, C was created to replace
assembly language for the implementation of an operating system
(thereby rendering that operating system ­ Unix ­ far more
portable than its predecessors). One of the main reasons for the
invention of C++ was to make C programmers more efficient.4 And
the first question asked when C programmers encounter C++ is,
"What kind of size and speed impact will I get?" If the answer
were, "Everything's great except for function calls when you'll
always have a little extra overhead," many people would stick with
C rather than make the change to C++. In addition, inline functions
would not be possible, because virtual functions must have an
address to put into the VTABLE. So the virtual function is an
option, and the language defaults to nonvirtual, which is the fastest
configuration. Stroustrup stated that his guideline was, "If you
don't use it, you don't pay for it."
Thus, the virtual keyword is provided for efficiency tuning. When
designing your classes, however, you shouldn't be worrying about
efficiency tuning. If you're going to use polymorphism, use virtual
3 Smalltalk, Java, and Python, for instance, use this approach with great success.
4 At Bell Labs, where C++ was invented, there are a lot of C programmers. Making
them all more efficient, even just a bit, saves the company many millions.
678
Thinking in C++
functions everywhere. You only need to look for functions that can
be made non-virtual when searching for ways to speed up your
code (and there are usually much bigger gains to be had in other
areas ­ a good profiler will do a better job of finding bottlenecks
than you will by making guesses).
Anecdotal evidence suggests that the size and speed impacts of
going to C++ are within 10 percent of the size and speed of C, and
often much closer to the same. The reason you might get better size
and speed efficiency is because you may design a C++ program in a
smaller, faster way than you would using C.
Abstract base classes and pure
virtual functions
Often in a design, you want the base class to present only an
interface for its derived classes. That is, you don't want anyone to
actually create an object of the base class, only to upcast to it so that
its interface can be used. This is accomplished by making that class
abstract, which happens if you give it at least one pure virtual
function. You can recognize a pure virtual function because it uses
the virtual keyword and is followed by = 0. If anyone tries to make
an object of an abstract class, the compiler prevents them. This is a
tool that allows you to enforce a particular design.
When an abstract class is inherited, all pure virtual functions must
be implemented, or the inherited class becomes abstract as well.
Creating a pure virtual function allows you to put a member
function in an interface without being forced to provide a possibly
meaningless body of code for that member function. At the same
time, a pure virtual function forces inherited classes to provide a
definition for it.
In all of the instrument examples, the functions in the base class
Instrumentwere always "dummy" functions. If these functions are
ever called, something is wrong. That's because the intent of
15: Polymorphism & Virtual Functions
679
Instrumentis to create a common interface for all of the classes
derived from it.
Instrument
virtual void play()
virtual char* what()
virtual void adjust()
Wind
Percussion
Stringed
void play()
void play()
void play()
char* what()
char* what()
char* what()
void adjust()
void adjust()
void adjust()
Woodwind
Brass
void play()
void play()
char* what()
char* what()
The only reason to establish the common interface is so it can be
expressed differently for each different subtype. It creates a basic
form that determines what's in common with all of the derived
classes ­ nothing else. So Instrumentis an appropriate candidate to
be an abstract class. You create an abstract class when you only
want to manipulate a set of classes through a common interface,
but the common interface doesn't need to have an implementation
(or at least, a full implementation).
If you have a concept like Instrumentthat works as an abstract
class, objects of that class almost always have no meaning. That is,
Instrumentis meant to express only the interface, and not a
680
Thinking in C++
particular implementation, so creating an object that is only an
Instrumentmakes no sense, and you'll probably want to prevent
the user from doing it. This can be accomplished by making all the
virtual functions in Instrumentprint error messages, but that
delays the appearance of the error information until runtime and it
requires reliable exhaustive testing on the part of the user. It is
much better to catch the problem at compile time.
Here is the syntax used for a pure virtual declaration:
virtual void f() = 0;
By doing this, you tell the compiler to reserve a slot for a function
in the VTABLE, but not to put an address in that particular slot.
Even if only one function in a class is declared as pure virtual, the
VTABLE is incomplete.
If the VTABLE for a class is incomplete, what is the compiler
supposed to do when someone tries to make an object of that class?
It cannot safely create an object of an abstract class, so you get an
error message from the compiler. Thus, the compiler guarantees the
purity of the abstract class. By making a class abstract, you ensure
that the client programmer cannot misuse it.
Here's Instrument4.cppmodified to use pure virtual functions.
Because the class has nothing but pure virtual functions, we call it a
pure abstract class:
//: C15:Instrument5.cpp
// Pure abstract base classes
#include <iostream>
using namespace std;
enum note { middleC, Csharp, Cflat }; // Etc.
class Instrument {
public:
// Pure virtual functions:
virtual void play(note) const = 0;
virtual char* what() const = 0;
// Assume this will modify the object:
15: Polymorphism & Virtual Functions
681
virtual void adjust(int) = 0;
};
// Rest of the file is the same ...
class Wind : public Instrument {
public:
void play(note) const {
cout << "Wind::play" << endl;
}
char* what() const { return "Wind"; }
void adjust(int) {}
};
class Percussion : public Instrument {
public:
void play(note) const {
cout << "Percussion::play" << endl;
}
char* what() const { return "Percussion"; }
void adjust(int) {}
};
class Stringed : public Instrument {
public:
void play(note) const {
cout << "Stringed::play" << endl;
}
char* what() const { return "Stringed"; }
void adjust(int) {}
};
class Brass : public Wind {
public:
void play(note) const {
cout << "Brass::play" << endl;
}
char* what() const { return "Brass"; }
};
class Woodwind : public Wind {
public:
void play(note) const {
cout << "Woodwind::play" << endl;
}
char* what() const { return "Woodwind"; }
682
Thinking in C++
};
// Identical function from before:
void tune(Instrument& i) {
// ...
i.play(middleC);
}
// New function:
void f(Instrument& i) { i.adjust(1); }
int main() {
Wind flute;
Percussion drum;
Stringed violin;
Brass flugelhorn;
Woodwind recorder;
tune(flute);
tune(drum);
tune(violin);
tune(flugelhorn);
tune(recorder);
f(flugelhorn);
} ///:~
Pure virtual functions are helpful because they make explicit the
abstractness of a class and tell both the user and the compiler how
it was intended to be used.
Note that pure virtual functions prevent an abstract class from
being passed into a function by value. Thus, it is also a way to
prevent object slicing (which will be described shortly). By making a
class abstract, you can ensure that a pointer or reference is always
used during upcasting to that class.
Just because one pure virtual function prevents the VTABLE from
being completed doesn't mean that you don't want function bodies
for some of the others. Often you will want to call a base-class
version of a function, even if it is virtual. It's always a good idea to
put common code as close as possible to the root of your hierarchy.
15: Polymorphism & Virtual Functions
683
Not only does this save code space, it allows easy propagation of
changes.
Pure virtual definitions
It's possible to provide a definition for a pure virtual function in the
base class. You're still telling the compiler not to allow objects of
that abstract base class, and the pure virtual functions must still be
defined in derived classes in order to create objects. However, there
may be a common piece of code that you want some or all of the
derived class definitions to call rather than duplicating that code in
every function.
Here's what a pure virtual definition looks like:
//: C15:PureVirtualDefinitions.cpp
// Pure virtual base definitions
#include <iostream>
using namespace std;
class Pet {
public:
virtual void speak() const = 0;
virtual void eat() const = 0;
// Inline pure virtual definitions illegal:
//!  virtual void sleep() const = 0 {}
};
// OK, not defined inline
void Pet::eat() const {
cout << "Pet::eat()" << endl;
}
void Pet::speak() const {
cout << "Pet::speak()" << endl;
}
class Dog : public Pet {
public:
// Use the common Pet code:
void speak() const { Pet::speak(); }
void eat() const { Pet::eat(); }
684
Thinking in C++
};
int main() {
Dog simba;  // Richard's dog
simba.speak();
simba.eat();
} ///:~
The slot in the Pet VTABLE is still empty, but there happens to be a
function by that name that you can call in the derived class.
The other benefit to this feature is that it allows you to change from
an ordinary virtual to a pure virtual without disturbing the existing
code. (This is a way for you to locate classes that don't override that
virtual function.)
Inheritance and the VTABLE
You can imagine what happens when you perform inheritance and
override some of the virtual functions. The compiler creates a new
VTABLE for your new class, and it inserts your new function
addresses using the base-class function addresses for any virtual
functions you don't override. One way or another, for every object
that can be created (that is, its class has no pure virtuals) there's
always a full set of function addresses in the VTABLE, so you'll
never be able to make a call to an address that isn't there (which
would be disastrous).
But what happens when you inherit and add new virtual functions
in the derived class? Here's a simple example:
//: C15:AddingVirtuals.cpp
// Adding virtuals in derivation
#include <iostream>
#include <string>
using namespace std;
class Pet {
string pname;
public:
15: Polymorphism & Virtual Functions
685
Pet(const string& petName) : pname(petName) {}
virtual string name() const { return pname; }
virtual string speak() const { return ""; }
};
class Dog : public Pet {
string name;
public:
Dog(const string& petName) : Pet(petName) {}
// New virtual function in the Dog class:
virtual string sit() const {
return Pet::name() + " sits";
}
string speak() const { // Override
return Pet::name() + " says 'Bark!'";
}
};
int main() {
Pet* p[] = {new Pet("generic"),new Dog("bob")};
cout << "p[0]->speak() = "
<< p[0]->speak() << endl;
cout << "p[1]->speak() = "
<< p[1]->speak() << endl;
//! cout << "p[1]->sit() = "
//!
<< p[1]->sit() << endl; // Illegal
} ///:~
The class Pet contains a two virtual functions: speak( )and name( ).
Dog adds a third virtual function called sit( ), as well as overriding
the meaning of speak( ) A diagram will help you visualize what's
.
happening. Here are the VTABLEs created by the compiler for Pet
and Dog:
&Pet::name
&Pet::name
&Pet::speak
&Dog::speak
&Dog::sit
686
Thinking in C++
Notice that the compiler maps the location of the speak( )address
into exactly the same spot in the Dog VTABLE as it is in the Pet
VTABLE. Similarly, if a class Pug is inherited from Dog, its version
of sit( ) would be placed in its VTABLE in exactly the same spot as
it is in Dog. This is because (as you saw with the assembly-
language example) the compiler generates code that uses a simple
numerical offset into the VTABLE to select the virtual function.
Regardless of the specific subtype the object belongs to, its VTABLE
is laid out the same way, so calls to the virtual functions will
always be made the same way.
In this case, however, the compiler is working only with a pointer
to a base-class object. The base class has only the speak( )and
name( ) functions, so those is the only functions the compiler will
allow you to call. How could it possibly know that you are working
with a Dog object, if it has only a pointer to a base-class object?
That pointer might point to some other type, which doesn't have a
sit( ) function. It may or may not have some other function address
at that point in the VTABLE, but in either case, making a virtual call
to that VTABLE address is not what you want to do. So the
compiler is doing its job by protecting you from making virtual
calls to functions that exist only in derived classes.
There are some less-common cases in which you may know that the
pointer actually points to an object of a specific subclass. If you
want to call a function that only exists in that subclass, then you
must cast the pointer. You can remove the error message produced
by the previous program like this:
((Dog*)p[1])->sit()
Here, you happen to know that p[1] points to a Dog object, but in
general you don't know that. If your problem is set up so that you
must know the exact types of all objects, you should rethink it,
because you're probably not using virtual functions properly.
However, there are some situations in which the design works best
(or you have no choice) if you know the exact type of all objects
15: Polymorphism & Virtual Functions
687
.
kept in a generic container. This is the problem of run-time type
identification (RTTI).
RTTI is all about casting base-class pointers down to derived-class
pointers ("up" and "down" are relative to a typical class diagram,
with the base class at the top). Casting up happens automatically,
with no coercion, because it's completely safe. Casting down is
unsafe because there's no compile time information about the
actual types, so you must know exactly what type the object is. If
you cast it into the wrong type, you'll be in trouble.
RTTI is described later in this chapter, and Volume 2 of this book
has a chapter devoted to the subject.
Object slicing
There is a distinct difference between passing the addresses of
objects and passing objects by value when using polymorphism.
All the examples you've seen here, and virtually all the examples
you should see, pass addresses and not values. This is because
addresses all have the same size5, so passing the address of an
object of a derived type (which is usually a bigger object) is the
same as passing the address of an object of the base type (which is
usually a smaller object). As explained before, this is the goal when
using polymorphism ­ code that manipulates a base type can
transparently manipulate derived-type objects as well.
If you upcast to an object instead of a pointer or reference,
something will happen that may surprise you: the object is "sliced"
until all that remains is the subobject that corresponds to the
destination type of your cast. In the following example you can see
what happens when an object is sliced:
//: C15:ObjectSlicing.cpp
5 Actually, not all pointers are the same size on all machines. In the context of this
discussion, however, they can be considered to be the same.
688
Thinking in C++
#include <iostream>
#include <string>
using namespace std;
class Pet {
string pname;
public:
Pet(const string& name) : pname(name) {}
virtual string name() const { return pname; }
virtual string description() const {
return "This is " + pname;
}
};
class Dog : public Pet {
string favoriteActivity;
public:
Dog(const string& name, const string& activity)
: Pet(name), favoriteActivity(activity) {}
string description() const {
return Pet::name() + " likes to " +
favoriteActivity;
}
};
void describe(Pet p) { // Slices the object
cout << p.description() << endl;
}
int main() {
Pet p("Alfred");
Dog d("Fluffy", "sleep");
describe(p);
describe(d);
} ///:~
The function describe( )is passed an object of type Pet by value. It
then calls the virtual function description( )for the Pet object. In
main( ), you might expect the first call to produce "This is Alfred,"
and the second to produce "Fluffy likes to sleep." In fact, both calls
use the base-class version of description( .)
15: Polymorphism & Virtual Functions
689
Two things are happening in this program. First, because
describe( )accepts a Pet object (rather than a pointer or reference),
any calls to describe( )will cause an object the size of Pet to be
pushed on the stack and cleaned up after the call. This means that if
an object of a class inherited from Pet is passed to describe( ) the
,
compiler accepts it, but it copies only the Pet portion of the object.
It slices the derived portion off of the object, like this:
Before Slice
After Slice
Dog vptr
Pet vptr
pname
pname
favoriteActivity
Now you may wonder about the virtual function call.
Dog::description( )
makes use of portions of both Pet (which still
exists) and Dog, which no longer exists because it was sliced off! So
what happens when the virtual function is called?
You're saved from disaster because the object is being passed by
value. Because of this, the compiler knows the precise type of the
object because the derived object has been forced to become a base
object. When passing by value, the copy-constructor for a Pet object
is used, which initializes the VPTR to the Pet VTABLE and copies
only the Pet parts of the object. There's no explicit copy-constructor
here, so the compiler synthesizes one. Under all interpretations, the
object truly becomes a Pet during slicing.
Object slicing actually removes part of the existing object as it
copies it into the new object, rather than simply changing the
meaning of an address as when using a pointer or reference.
Because of this, upcasting into an object is not done often; in fact,
it's usually something to watch out for and prevent. Note that, in
this example, if description( )were made into a pure virtual
function in the base class (which is not unreasonable, since it
690
Thinking in C++
doesn't really do anything in the base class), then the compiler
would prevent object slicing because that wouldn't allow you to
"create" an object of the base type (which is what happens when
you upcast by value). This could be the most important value of
pure virtual functions: to prevent object slicing by generating a
compile-time error message if someone tries to do it.
Overloading & overriding
In Chapter 14, you saw that redefining an overloaded function in
the base class hides all of the other base-class versions of that
function. When virtual functions are involved the behavior is a
little different. Consider a modified version of the
NameHiding.cppexample from Chapter 14:
//: C15:NameHiding2.cpp
// Virtual functions restrict overloading
#include <iostream>
#include <string>
using namespace std;
class Base {
public:
virtual int f() const {
cout << "Base::f()\n";
return 1;
}
virtual void f(string) const {}
virtual void g() const {}
};
class Derived1 : public Base {
public:
void g() const {}
};
class Derived2 : public Base {
public:
// Overriding a virtual function:
int f() const {
cout << "Derived2::f()\n";
15: Polymorphism & Virtual Functions
691
return 2;
}
};
class Derived3 : public Base {
public:
// Cannot change return type:
//! void f() const{ cout << "Derived3::f()\n";}
};
class Derived4 : public Base {
public:
// Change argument list:
int f(int) const {
cout << "Derived4::f()\n";
return 4;
}
};
int main() {
string s("hello");
Derived1 d1;
int x = d1.f();
d1.f(s);
Derived2 d2;
x = d2.f();
//!  d2.f(s); // string version hidden
Derived4 d4;
x = d4.f(1);
//!  x = d4.f(); // f() version hidden
//!  d4.f(s); // string version hidden
Base& br = d4; // Upcast
//!  br.f(1); // Derived version unavailable
br.f(); // Base version available
br.f(s); // Base version abailable
} ///:~
The first thing to notice is that in Derived3 the compiler will not
,
allow you to change the return type of an overridden function (it
will allow it if f( ) is not virtual). This is an important restriction
because the compiler must guarantee that you can polymorphically
call the function through the base class, and if the base class is
692
Thinking in C++
expecting an int to be returned from f( ), then the derived-class
version of f( ) must keep that contract or else things will break.
The rule shown in Chapter 14 still works: if you override one of the
overloaded member functions in the base class, the other
overloaded versions become hidden in the derived class. In main( )
the code that tests Derived4shows that this happens even if the
new version of f( ) isn't actually overriding an existing virtual
function interface ­ both of the base-class versions of f( ) are hidden
by f(int). However, if you upcast d4 to Base, then only the base-
class versions are available (because that's what the base-class
contract promises) and the derived-class version is not available
(because it isn't specified in the base class).
Variant return type
The Derived3class above suggests that you cannot modify the
return type of a virtual function during overriding. This is
generally true, but there is a special case in which you can slightly
modify the return type. If you're returning a pointer or a reference
to a base class, then the overridden version of the function may
return a pointer or reference to a class derived from what the base
returns. For example:
//: C15:VariantReturn.cpp
// Returning a pointer or reference to a derived
// type during ovverriding
#include <iostream>
#include <string>
using namespace std;
class PetFood {
public:
virtual string foodType() const = 0;
};
class Pet {
public:
virtual string type() const = 0;
virtual PetFood* eats() = 0;
15: Polymorphism & Virtual Functions
693
};
class Bird : public Pet {
public:
string type() const { return "Bird"; }
class BirdFood : public PetFood {
public:
string foodType() const {
return "Bird food";
}
};
// Upcast to base type:
PetFood* eats() { return &bf; }
private:
BirdFood bf;
};
class Cat : public Pet {
public:
string type() const { return "Cat"; }
class CatFood : public PetFood {
public:
string foodType() const { return "Birds"; }
};
// Return exact type instead:
CatFood* eats() { return &cf; }
private:
CatFood cf;
};
int main() {
Bird b;
Cat c;
Pet* p[] = { &b, &c, };
for(int i = 0; i < sizeof p / sizeof *p; i++)
cout << p[i]->type() << " eats "
<< p[i]->eats()->foodType() << endl;
// Can return the exact type:
Cat::CatFood* cf = c.eats();
Bird::BirdFood* bf;
// Cannot return the exact type:
//!  bf = b.eats();
// Must downcast:
bf = dynamic_cast<Bird::BirdFood*>(b.eats());
} ///:~
694
Thinking in C++
The Pet::eats( )member function returns a pointer to a PetFood. In
Bird, this member function is overloaded exactly as in the base
class, including the return type. That is, Bird::eats( )upcasts the
BirdFoodto a PetFood.
But in Cat, the return type of eats( ) is a pointer to CatFood, a type
derived from PetFood. The fact that the return type is inherited
from the return type of the base-class function is the only reason
this compiles. That way, the contract is still fulfilled; eats( ) always
returns a PetFood pointer.
If you think polymorphically, this doesn't seem necessary. Why not
just upcast all the return types to PetFood* just as Bird::eats( )did?
,
This is typically a good solution, but at the end of main( ), you see
the difference: Cat::eats( )can return the exact type of PetFood,
whereas the return value of Bird::eats( )must be downcast to the
exact type.
So being able to return the exact type is a little more general, and
doesn't lose the specific type information by automatically
upcasting. However, returning the base type will generally solve
your problems so this is a rather specialized feature.
virtual functions & constructors
When an object containing virtual functions is created, its VPTR
must be initialized to point to the proper VTABLE. This must be
done before there's any possibility of calling a virtual function. As
you might guess, because the constructor has the job of bringing an
object into existence, it is also the constructor's job to set up the
VPTR. The compiler secretly inserts code into the beginning of the
constructor that initializes the VPTR. And as described in Chapter
14, if you don't explicitly create a constructor for a class, the
compiler will synthesize one for you. If the class has virtual
functions, the synthesized constructor will include the proper
VPTR initialization code. This has several implications.
15: Polymorphism & Virtual Functions
695
The first concerns efficiency. The reason for inline functions is to
reduce the calling overhead for small functions. If C++ didn't
provide inline functions, the preprocessor might be used to create
these "macros." However, the preprocessor has no concept of
access or classes, and therefore couldn't be used to create member
function macros. In addition, with constructors that must have
hidden code inserted by the compiler, a preprocessor macro
wouldn't work at all.
You must be aware when hunting for efficiency holes that the
compiler is inserting hidden code into your constructor function.
Not only must it initialize the VPTR, it must also check the value of
this (in case the operatornew returns zero) and call base-class
constructors. Taken together, this code can impact what you
thought was a tiny inline function call. In particular, the size of the
constructor may overwhelm the savings you get from reduced
function-call overhead. If you make a lot of inline constructor calls,
your code size can grow without any benefits in speed.
Of course, you probably won't make all tiny constructors non-
inline right away, because they're much easier to write as inlines.
But when you're tuning your code, remember to consider removing
the inline constructors.
Order of constructor calls
The second interesting facet of constructors and virtual functions
concerns the order of constructor calls and the way virtual calls are
made within constructors.
All base-class constructors are always called in the constructor for
an inherited class. This makes sense because the constructor has a
special job: to see that the object is built properly. A derived class
has access only to its own members, and not those of the base class.
Only the base-class constructor can properly initialize its own
elements. Therefore it's essential that all constructors get called;
otherwise the entire object wouldn't be constructed properly. That's
696
Thinking in C++
why the compiler enforces a constructor call for every portion of a
derived class. It will call the default constructor if you don't
explicitly call a base-class constructor in the constructor initializer
list. If there is no default constructor, the compiler will complain.
The order of the constructor calls is important. When you inherit,
you know all about the base class and can access any public and
protectedmembers of the base class. This means you must be able
to assume that all the members of the base class are valid when
you're in the derived class. In a normal member function,
construction has already taken place, so all the members of all parts
of the object have been built. Inside the constructor, however, you
must be able to assume that all members that you use have been
built. The only way to guarantee this is for the base-class
constructor to be called first. Then when you're in the derived-class
constructor, all the members you can access in the base class have
been initialized. "Knowing all members are valid" inside the
constructor is also the reason that, whenever possible, you should
initialize all member objects (that is, objects placed in the class
using composition) in the constructor initializer list. If you follow
this practice, you can assume that all base class members and
member objects of the current object have been initialized.
Behavior of virtual functions inside
constructors
The hierarchy of constructor calls brings up an interesting
dilemma. What happens if you're inside a constructor and you call
a virtual function? Inside an ordinary member function you can
imagine what will happen ­ the virtual call is resolved at runtime
because the object cannot know whether it belongs to the class the
member function is in, or some class derived from it. For
consistency, you might think this is what should happen inside
constructors.
15: Polymorphism & Virtual Functions
697
This is not the case. If you call a virtual function inside a
constructor, only the local version of the function is used. That is,
the virtual mechanism doesn't work within the constructor.
This behavior makes sense for two reasons. Conceptually, the
constructor's job is to bring the object into existence (which is
hardly an ordinary feat). Inside any constructor, the object may
only be partially formed ­ you can only know that the base-class
objects have been initialized, but you cannot know which classes
are inherited from you. A virtual function call, however, reaches
"forward" or "outward" into the inheritance hierarchy. It calls a
function in a derived class. If you could do this inside a constructor,
you'd be calling a function that might manipulate members that
hadn't been initialized yet, a sure recipe for disaster.
The second reason is a mechanical one. When a constructor is
called, one of the first things it does is initialize its VPTR. However,
it can only know that it is of the "current" type ­ the type the
constructor was written for. The constructor code is completely
ignorant of whether or not the object is in the base of another class.
When the compiler generates code for that constructor, it generates
code for a constructor of that class, not a base class and not a class
derived from it (because a class can't know who inherits it). So the
VPTR it uses must be for the VTABLE of that class. The VPTR
remains initialized to that VTABLE for the rest of the object's
lifetime unless this isn't the last constructor call. If a more-derived
constructor is called afterwards, that constructor sets the VPTR to
its VTABLE, and so on, until the last constructor finishes. The state
of the VPTR is determined by the constructor that is called last.
This is another reason why the constructors are called in order from
base to most-derived.
But while all this series of constructor calls is taking place, each
constructor has set the VPTR to its own VTABLE. If it uses the
virtual mechanism for function calls, it will produce only a call
through its own VTABLE, not the most-derived VTABLE (as would
698
Thinking in C++
be the case after all the constructors were called). In addition, many
compilers recognize that a virtual function call is being made inside
a constructor, and perform early binding because they know that
late-binding will produce a call only to the local function. In either
event, you won't get the results you might initially expect from a
virtual function call inside a constructor.
Destructors and virtual destructors
You cannot use the virtual keyword with constructors, but
destructors can and often must be virtual.
The constructor has the special job of putting an object together
piece-by-piece, first by calling the base constructor, then the more
derived constructors in order of inheritance (it must also call
member-object constructors along the way). Similarly, the
destructor has a special job: it must disassemble an object that may
belong to a hierarchy of classes. To do this, the compiler generates
code that calls all the destructors, but in the reverse order that they
are called by the constructor. That is, the destructor starts at the
most-derived class and works its way down to the base class. This
is the safe and desirable thing to do because the current destructor
can always know that the base-class members are alive and active.
If you need to call a base-class member function inside your
destructor, it is safe to do so. Thus, the destructor can perform its
own cleanup, then call the next-down destructor, which will
perform its own cleanup, etc. Each destructor knows what its class
is derived from, but not what is derived from it.
You should keep in mind that constructors and destructors are the
only places where this hierarchy of calls must happen (and thus the
proper hierarchy is automatically generated by the compiler). In all
other functions, only that function will be called (and not base-class
versions), whether it's virtual or not. The only way for base-class
versions of the same function to be called in ordinary functions
(virtual or not) is if you explicitly call that function.
15: Polymorphism & Virtual Functions
699
Normally, the action of the destructor is quite adequate. But what
happens if you want to manipulate an object through a pointer to
its base class (that is, manipulate the object through its generic
interface)? This activity is a major objective in object-oriented
programming. The problem occurs when you want to delete a
pointer of this type for an object that has been created on the heap
with new. If the pointer is to the base class, the compiler can only
know to call the base-class version of the destructor during delete.
Sound familiar? This is the same problem that virtual functions
were created to solve for the general case. Fortunately, virtual
functions work for destructors as they do for all other functions
except constructors.
//: C15:VirtualDestructors.cpp
// Behavior of virtual vs. non-virtual destructor
#include <iostream>
using namespace std;
class Base1 {
public:
~Base1() { cout << "~Base1()\n"; }
};
class Derived1 : public Base1 {
public:
~Derived1() { cout << "~Derived1()\n"; }
};
class Base2 {
public:
virtual ~Base2() { cout << "~Base2()\n"; }
};
class Derived2 : public Base2 {
public:
~Derived2() { cout << "~Derived2()\n"; }
};
int main() {
Base1* bp = new Derived1; // Upcast
delete bp;
Base2* b2p = new Derived2; // Upcast
700
Thinking in C++
delete b2p;
} ///:~
When you run the program, you'll see that delete bponly calls the
base-class destructor, while delete b2pcalls the derived-class
destructor followed by the base-class destructor, which is the
behavior we desire. Forgetting to make a destructor virtual is an
insidious bug because it often doesn't directly affect the behavior of
your program, but it can quietly introduce a memory leak. Also, the
fact that some destruction is occurring can further mask the
problem.
Even though the destructor, like the constructor, is an
"exceptional" function, it is possible for the destructor to be virtual
because the object already knows what type it is (whereas it doesn't
during construction). Once an object has been constructed, its
VPTR is initialized, so virtual function calls can take place.
Pure virtual destructors
While pure virtual destructors are legal in Standard C++, there is
an added constraint when using them: you must provide a function
body for the pure virtual destructor. This seems counterintuitive;
how can a virtual function be "pure" if it needs a function body?
But if you keep in mind that constructors and destructors are
special operations it makes more sense, especially if you remember
that all destructors in a class hierarchy are always called. If you
could leave off the definition for a pure virtual destructor, what
function body would be called during destruction? Thus, it's
absolutely necessary that the compiler and linker enforce the
existence of a function body for a pure virtual destructor.
If it's pure, but it has to have a function body, what's the value of
it? The only difference you'll see between the pure and non-pure
virtual destructor is that the pure virtual destructor does cause the
base class to be abstract, so you cannot create an object of the base
15: Polymorphism & Virtual Functions
701
class (although this would also be true if any other member
function of the base class were pure virtual).
Things are a bit confusing, however, when you inherit a class from
one that contains a pure virtual destructor. Unlike every other pure
virtual function, you are not required to provide a definition of a
pure virtual destructor in the derived class. The fact that the
following compiles and links is the proof:
//: C15:UnAbstract.cpp
// Pure virtual destructors
// seem to behave strangely
class AbstractBase {
public:
virtual ~AbstractBase() = 0;
};
AbstractBase::~AbstractBase() {}
class Derived : public AbstractBase {};
// No overriding of destructor necessary?
int main() { Derived d; } ///:~
Normally, a pure virtual function in a base class would cause the
derived class to be abstract unless it (and all other pure virtual
functions) is given a definition. But here, this seems not to be the
case. However, remember that the compiler automatically creates a
destructor definition for every class if you don't create one. That's
what's happening here ­ the base class destructor is being quietly
overridden, and thus the definition is being provided by the
compiler and Derived is not actually abstract.
This brings up an interesting question: What is the point of a pure
virtual destructor? Unlike an ordinary pure virtual function, you
must give it a function body. In a derived class, you aren't forced to
provide a definition since the compiler synthesizes the destructor
for you. So what's the difference between a regular virtual
destructor and a pure virtual destructor?
702
Thinking in C++
The only distinction occurs when you have a class that only has a
single pure virtual function: the destructor. In this case, the only
effect of the purity of the destructor is to prevent the instantiation
of the base class. If there were any other pure virtual functions,
they would prevent the instantiation of the base class, but if there
are no others, then the pure virtual destructor will do it. So, while
the addition of a virtual destructor is essential, whether it's pure or
not isn't so important.
When you run the following example, you can see that the pure
virtual function body is called after the derived class version, just
as with any other destructor:
//: C15:PureVirtualDestructors.cpp
// Pure virtual destructors
// require a function body
#include <iostream>
using namespace std;
class Pet {
public:
virtual ~Pet() = 0;
};
Pet::~Pet() {
cout << "~Pet()" << endl;
}
class Dog : public Pet {
public:
~Dog() {
cout << "~Dog()" << endl;
}
};
int main() {
Pet* p = new Dog; // Upcast
delete p; // Virtual destructor call
} ///:~
15: Polymorphism & Virtual Functions
703
As a guideline, any time you have a virtual function in a class, you
should immediately add a virtual destructor (even if it does
nothing). This way, you ensure against any surprises later.
Virtuals in destructors
There's something that happens during destruction that you might
not immediately expect. If you're inside an ordinary member
function and you call a virtual function, that function is called
using the late-binding mechanism. This is not true with destructors,
virtual or not. Inside a destructor, only the "local" version of the
member function is called; the virtual mechanism is ignored.
//: C15:VirtualsInDestructors.cpp
// Virtual calls inside destructors
#include <iostream>
using namespace std;
class Base {
public:
virtual ~Base() {
cout << "Base1()\n";
f();
}
virtual void f() { cout << "Base::f()\n"; }
};
class Derived : public Base {
public:
~Derived() { cout << "~Derived()\n"; }
void f() { cout << "Derived::f()\n"; }
};
int main() {
Base* bp = new Derived; // Upcast
delete bp;
} ///:~
During the destructor call, Derived::f( )is not called, even though
f( ) is virtual.
704
Thinking in C++
Why is this? Suppose the virtual mechanism were used inside the
destructor. Then it would be possible for the virtual call to resolve
to a function that was "farther out" (more derived) on the
inheritance hierarchy than the current destructor. But destructors
are called from the "outside in" (from the most-derived destructor
down to the base destructor), so the actual function called would
rely on portions of an object that have already been destroyed!
Instead, the compiler resolves the calls at compile-time and calls
only the "local" version of the function. Notice that the same is true
for the constructor (as described earlier), but in the constructor's
case the type information wasn't available, whereas in the
destructor the information (that is, the VPTR) is there, but is isn't
reliable.
Creating an object-based hierarchy
An issue that has been recurring throughout this book during the
demonstration of the container classes Stack and Stash is the
"ownership problem." The "owner" refers to who or what is
responsible for calling delete for objects that have been created
dynamically (using new). The problem when using containers is
that they need to be flexible enough to hold different types of
objects. To do this, the containers have held void pointers and so
they haven't known the type of object they've held. Deleting a void
pointer doesn't call the destructor, so the container couldn't be
responsible for cleaning up its objects.
One solution was presented in the example C14:InheritStack.cpp
,
in which the Stack was inherited into a new class that accepted and
produced only string pointers. Since it knew that it could hold only
pointers to string objects, it could properly delete them. This was a
nice solution, but it requires you to inherit a new container class for
each type that you want to hold in the container. (Although this
seems tedious now, it will actually work quite well in Chapter 16,
when templates are introduced.)
15: Polymorphism & Virtual Functions
705
The problem is that you want the container to hold more than one
type, but you don't want to use void pointers. Another solution is
to use polymorphism by forcing all the objects held in the container
to be inherited from the same base class. That is, the container
holds the objects of the base class, and then you can call virtual
functions ­ in particular, you can call virtual destructors to solve
the ownership problem.
This solution uses what is referred to as a singly-rooted hierarchy or
an object-based hierarchy (because the root class of the hierarchy is
usually named "Object"). It turns out that there are many other
benefits to using a singly-rooted hierarchy; in fact, every other
object-oriented language but C++ enforces the use of such a
hierarchy ­ when you create a class, you are automatically
inheriting it directly or indirectly from a common base class, a base
class that was established by the creators of the language. In C++, it
was thought that the enforced use of this common base class would
cause too much overhead, so it was left out. However, you can
choose to use a common base class in your own projects, and this
subject will be examined further in Volume 2 of this book.
To solve the ownership problem, we can create an extremely simple
Object for the base class, which contains only a virtual destructor.
The Stack can then hold classes inherited from Object:
//: C15:OStack.h
// Using a singly-rooted hierarchy
#ifndef OSTACK_H
#define OSTACK_H
class Object {
public:
virtual ~Object() = 0;
};
// Required definition:
inline Object::~Object() {}
class Stack {
706
Thinking in C++
struct Link {
Object* data;
Link* next;
Link(Object* dat, Link* nxt) :
data(dat), next(nxt) {}
}* head;
public:
Stack() : head(0) {}
~Stack(){
while(head)
delete pop();
}
void push(Object* dat) {
head = new Link(dat, head);
}
Object* peek() const {
return head ? head->data : 0;
}
Object* pop() {
if(head == 0) return 0;
Object* result = head->data;
Link* oldHead = head;
head = head->next;
delete oldHead;
return result;
}
};
#endif // OSTACK_H ///:~
To simplify things by keeping everything in the header file, the
(required) definition for the pure virtual destructor is inlined into
the header file, and pop( ) (which might be considered too large for
inlining) is also inlined.
Link objects now hold pointers to Object rather than void pointers,
and the Stack will only accept and return Object pointers. Now
Stack is much more flexible, since it will hold lots of different types
but will also destroy any objects that are left on the Stack. The new
limitation (which will be finally removed when templates are
applied to the problem in Chapter 16) is that anything that is placed
on the Stack must be inherited from Object. That's fine if you are
starting your class from scratch, but what if you already have a
15: Polymorphism & Virtual Functions
707
class such as string that you want to be able to put onto the Stack?
In this case, the new class must be both a string and an Object,
which means it must be inherited from both classes. This is called
multiple inheritance and it is the subject of an entire chapter in
Volume 2 of this book (downloadable from ).
When you read that chapter, you'll see that multiple inheritance
can be fraught with complexity, and is a feature you should use
sparingly. In this situation, however, everything is simple enough
that we don't trip across any multiple inheritance pitfalls:
//: C15:OStackTest.cpp
//{T} OStackTest.cpp
#include "OStack.h"
#include "../require.h"
#include <fstream>
#include <iostream>
#include <string>
using namespace std;
// Use multiple inheritance. We want
// both a string and an Object:
class MyString: public string, public Object {
public:
~MyString() {
cout << "deleting string: " << *this << endl;
}
MyString(string s) : string(s) {}
};
int main(int argc, char* argv[]) {
requireArgs(argc, 1); // File name is argument
ifstream in(argv[1]);
assure(in, argv[1]);
Stack textlines;
string line;
// Read file and store lines in the stack:
while(getline(in, line))
textlines.push(new MyString(line));
// Pop some lines from the stack:
MyString* s;
for(int i = 0; i < 10; i++) {
if((s=(MyString*)textlines.pop())==0) break;
708
Thinking in C++
cout << *s << endl;
delete s;
}
cout << "Letting the destructor do the rest:"
<< endl;
} ///:~
Although this is similar to the previous version of the test program
for Stack, you'll notice that only 10 elements are popped from the
stack, which means there are probably some objects remaining.
Because the Stack knows that it holds Objects, the destructor can
properly clean things up, and you'll see this in the output of the
program, since the MyStringobjects print messages as they are
destroyed.
Creating containers that hold Objects is not an unreasonable
approach ­ if you have a singly-rooted hierarchy (enforced either
by the language or by the requirement that every class inherit from
Object). In that case, everything is guaranteed to be an Object and
so it's not very complicated to use the containers. In C++, however,
you cannot expect this from every class, so you're bound to trip
over multiple inheritance if you take this approach. You'll see in
Chapter 16 that templates solve the problem in a much simpler and
more elegant fashion.
Operator overloading
You can make operators virtual just like other member functions.
Implementing virtual operators often becomes confusing, however,
because you may be operating on two objects, both with unknown
types. This is usually the case with mathematical components (for
which you often overload operators). For example, consider a
system that deals with matrices, vectors and scalar values, all three
of which are derived from class Math:
//: C15:OperatorPolymorphism.cpp
// Polymorphism with overloaded operators
#include <iostream>
15: Polymorphism & Virtual Functions
709
using namespace std;
class Matrix;
class Scalar;
class Vector;
class Math {
public:
virtual Math& operator*(Math& rv)
= 0;
virtual Math& multiply(Matrix*) =
0;
virtual Math& multiply(Scalar*) =
0;
virtual Math& multiply(Vector*) =
0;
virtual ~Math() {}
};
class Matrix : public Math {
public:
Math& operator*(Math& rv) {
return rv.multiply(this);
// 2nd dispatch
}
Math& multiply(Matrix*) {
cout << "Matrix * Matrix"
<< endl;
return *this;
}
Math& multiply(Scalar*) {
cout << "Scalar * Matrix"
<< endl;
return *this;
}
Math& multiply(Vector*) {
cout << "Vector * Matrix"
<< endl;
return *this;
}
};
class Scalar : public Math  {
public:
Math& operator*(Math& rv) {
return rv.multiply(this); // 2nd dispatch
}
Math& multiply(Matrix*) {
cout << "Matrix * Scalar" << endl;
return *this;
}
Math& multiply(Scalar*) {
cout << "Scalar * Scalar" << endl;
710
Thinking in C++
return *this;
}
Math& multiply(Vector*) {
cout << "Vector * Scalar" << endl;
return *this;
}
};
class Vector : public Math  {
public:
Math& operator*(Math& rv) {
return rv.multiply(this);
// 2nd dispatch
}
Math& multiply(Matrix*) {
cout << "Matrix * Vector"
<< endl;
return *this;
}
Math& multiply(Scalar*) {
cout << "Scalar * Vector"
<< endl;
return *this;
}
Math& multiply(Vector*) {
cout << "Vector * Vector"
<< endl;
return *this;
}
};
int main() {
Matrix m; Vector v; Scalar s;
Math* math[] = { &m, &v, &s };
for(int i = 0; i < 3; i++)
for(int j = 0; j < 3; j++) {
Math& m1 = *math[i];
Math& m2 = *math[j];
m1 * m2;
}
} ///:~
For simplicity, only the operator*has been overloaded. The goal is
to be able to multiply any two Math objects and produce the
desired result ­ and note that multiplying a matrix by a vector is a
very different operation than multiplying a vector by a matrix.
15: Polymorphism & Virtual Functions
711
The problem is that, in main( ), the expression m1 * m2 contains
two upcast Math references, and thus two objects of unknown
type. A virtual function is only capable of making a single dispatch
­ that is, determining the type of one unknown object. To
determine both types a technique called multiple dispatching is used
in this example, whereby what appears to be a single virtual
function call results in a second virtual call. By the time this second
call is made, you've determined both types of object, and can
perform the proper activity. It's not transparent at first, but if you
stare at the example for awhile it should begin to make sense. This
topic is explored in more depth in the Design Patterns chapter in
Volume 2, which you can download at .
Downcasting
As you might guess, since there's such a thing as upcasting ­
moving up an inheritance hierarchy ­ there should also be
downcasting to move down a hierarchy. But upcasting is easy since
as you move up an inheritance hierarchy the classes always
converge to more general classes. That is, when you upcast you are
always clearly derived from an ancestor class (typically only one,
except in the case of multiple inheritance) but when you downcast
there are usually several possibilities that you could cast to. More
specifically, a Circle is a type of Shape (that's the upcast), but if
you try to downcast a Shape it could be a Circle, Square, Triangle
,
etc. So the dilemma is figuring out a way to safely downcast. (But
an even more important issue is asking yourself why you're
downcasting in the first place instead of just using polymorphism
to automatically figure out the correct type. The avoidance of
downcasting is covered in Volume 2 of this book.)
C++ provides a special explicit cast (introduced in Chapter 3) called
dynamic_castthat is a type-safe downcast operation. When you use
dynamic_castto try to cast down to a particular type, the return
value will be a pointer to the desired type only if the cast is proper
712
Thinking in C++
and successful, otherwise it will return zero to indicate that this
was not the correct type. Here's a minimal example:
//: C15:DynamicCast.cpp
#include <iostream>
using namespace std;
class Pet { public: virtual ~Pet(){}};
class Dog : public Pet {};
class Cat : public Pet {};
int main() {
Pet* b = new Cat; // Upcast
// Try to cast it to Dog*:
Dog* d1 = dynamic_cast<Dog*>(b);
// Try to cast it to Cat*:
Cat* d2 = dynamic_cast<Cat*>(b);
cout << "d1 = " << (long)d1 << endl;
cout << "d2 = " << (long)d2 << endl;
} ///:~
When you use dynamic_cast you must be working with a true
,
polymorphic hierarchy ­ one with virtual functions ­ because
dynamic_castuses information stored in the VTABLE to determine
the actual type. Here, the base class contains a virtual destructor
and that suffices. In main( ), a Cat pointer is upcast to a Pet, and
then a downcast is attempted to both a Dog pointer and a Cat
pointer. Both pointers are printed, and you'll see when you run the
program that the incorrect downcast produces a zero result. Of
course, whenever you downcast you are responsible for checking to
make sure that the result of the cast is nonzero. Also, you should
not assume that the pointer will be exactly the same, because
sometimes pointer adjustments take place during upcasting and
downcasting (in particular, with multiple inheritance).
A dynamic_castrequires a little bit of extra overhead to run; not
much, but if you're doing a lot of dynamic_cast  (in which case
ing
you should be seriously questioning your program design) this
may become a performance issue. In some cases you may know
something special during downcasting that allows you to say for
15: Polymorphism & Virtual Functions
713
sure what type you're dealing with, in which case the extra
overhead of the dynamic_castbecomes unnecessary, and you can
use a static_castinstead. Here's how it might work:
//: C15:StaticHierarchyNavigation.cpp
// Navigating class hierarchies with static_cast
#include <iostream>
#include <typeinfo>
using namespace std;
class
Shape { public: virtual ~Shape() {}; };
class
Circle : public Shape {};
class
Square : public Shape {};
class
Other {};
int main() {
Circle c;
Shape* s = &c; // Upcast: normal and OK
// More explicit but unnecessary:
s = static_cast<Shape*>(&c);
// (Since upcasting is such a safe and common
// operation, the cast becomes cluttering)
Circle* cp = 0;
Square* sp = 0;
// Static Navigation of class hierarchies
// requires extra type information:
if(typeid(s) == typeid(cp)) // C++ RTTI
cp = static_cast<Circle*>(s);
if(typeid(s) == typeid(sp))
sp = static_cast<Square*>(s);
if(cp != 0)
cout << "It's a circle!" << endl;
if(sp != 0)
cout << "It's a square!" << endl;
// Static navigation is ONLY an efficiency hack;
// dynamic_cast is always safer. However:
// Other* op = static_cast<Other*>(s);
// Conveniently gives an error message, while
Other* op2 = (Other*)s;
// does not
} ///:~
In this program, a new feature is used that is not fully described
until Volume 2 of this book, where a chapter is given to the topic:
714
Thinking in C++
C++'s run-time type information (RTTI) mechanism. RTTI allows you
to discover type information that has been lost by upcasting. The
dynamic_castis actually one form of RTTI. Here, the typeid
keyword (declared in the header file <typeinfo> is used to detect
)
the types of the pointers. You can see that the type of the upcast
Shape pointer is successively compared to a Circle pointer and a
Square pointer to see if there's a match. There's more to RTTI than
typeid, and you can also imagine that it would be fairly easy to
implement your own type information system using a virtual
function.
A Circle object is created and the address is upcast to a Shape
pointer; the second version of the expression shows how you can
use static_castto be more explicit about the upcast. However, since
an upcast is always safe and it's a common thing to do, I consider
an explicit cast for upcasting to be cluttering and unnecessary.
RTTI is used to determine the type, and then static_castis used to
perform the downcast. But notice that in this design the process is
effectively the same as using dynamic_cast and the client
,
programmer must do some testing to discover the cast that was
actually successful. You'll typically want a situation that's more
deterministic than in the example above before using static_cast
rather than dynamic_cast(and, again, you want to carefully
examine your design before using dynamic_cast
).
If a class hierarchy has no virtual functions (which is a questionable
design) or if you have other information that allows you to safely
downcast, it's a tiny bit faster to do the downcast statically than
with dynamic_cast In addition, static_castwon't allow you to cast
.
out of the hierarchy, as the traditional cast will, so it's safer.
However, statically navigating class hierarchies is always risky and
you should use dynamic_castunless you have a special situation.
15: Polymorphism & Virtual Functions
715
Summary
Polymorphism ­ implemented in C++ with virtual functions ­
means "different forms." In object-oriented programming, you
have the same face (the common interface in the base class) and
different forms using that face: the different versions of the virtual
functions.
You've seen in this chapter that it's impossible to understand, or
even create, an example of polymorphism without using data
abstraction and inheritance. Polymorphism is a feature that cannot
be viewed in isolation (like const or a switch statement, for
example), but instead works only in concert, as part of a "big
picture" of class relationships. People are often confused by other,
non-object-oriented features of C++, like overloading and default
arguments, which are sometimes presented as object-oriented.
Don't be fooled; if it isn't late binding, it isn't polymorphism.
To use polymorphism ­ and thus, object-oriented techniques ­
effectively in your programs you must expand your view of
programming to include not just members and messages of an
individual class, but also the commonality among classes and their
relationships with each other. Although this requires significant
effort, it's a worthy struggle, because the results are faster program
development, better code organization, extensible programs, and
easier code maintenance.
Polymorphism completes the object-oriented features of the
language, but there are two more major features in C++: templates
(which are introduced in Chapter 16 and covered in much more
detail in Volume 2), and exception handling (which is covered in
Volume 2). These features provide you as much increase in
programming power as each of the object-oriented features:
abstract data typing, inheritance, and polymorphism.
716
Thinking in C++
Exercises
Solutions to selected exercises can be found in the electronic document The Thinking in C++ Annotated
Solution Guide, available for a small fee from .
1.
Create a simple "shape" hierarchy: a base class called
Shape and derived classes called Circle, Square, and
Triangle In the base class, make a virtual function called
.
draw( ),and override this in the derived classes. Make an
array of pointers to Shape objects that you create on the
heap (and thus perform upcasting of the pointers), and
call draw( ) through the base-class pointers, to verify the
behavior of the virtual function. If your debugger
supports it, single-step through the code.
2.
Modify Exercise 1 so draw( ) is a pure virtual function.
Try creating an object of type Shape. Try to call the pure
virtual function inside the constructor and see what
happens. Leaving it as a pure virtual, give draw( ) a
definition.
3.
Expanding on Exercise 2, create a function that takes a
Shape object by value and try to upcast a derived object in
as an argument. See what happens. Fix the function by
taking a reference to the Shape object.
4.
Modify C14:Combined.cpp  that f( ) is virtual in the
so
base class. Change main( ) to perform an upcast and a
virtual call.
5.
Modify Instrument3.cppby adding a virtual prepare( )
function. Call prepare( )inside tune( ).
6.
Create an inheritance hierarchy of Rodent: Mouse,
Gerbil, Hamster, etc. In the base class, provide methods
that are common to all Rodents, and redefine these in the
derived classes to perform different behaviors depending
on the specific type of Rodent. Create an array of
pointers to Rodent, fill it with different specific types of
Rodents, and call your base-class methods to see what
happens.
15: Polymorphism & Virtual Functions
717
7.
Modify Exercise 6 so that you use a vector<Rodent*>
instead of an array of pointers. Make sure that memory is
cleaned up properly.
8.
Starting with the previous Rodent hierarchy, inherit
BlueHamsterfrom Hamster (yes, there is such a thing; I
had one when I was a kid), override the base-class
methods, and show that the code that calls the base-class
methods doesn't need to change in order to
accommodate the new type.
9.
Starting with the previous Rodent hierarchy, add a non
virtual destructor, create an object of class Hamster using
new, upcast the pointer to a Rodent*, and delete the
pointer to show that it doesn't call all the destructors in
the hierarchy. Change the destructor to be virtual and
demonstrate that the behavior is now correct.
10.
Starting with the previous Rodent hierarchy, modify
Rodent so it is a pure abstract base class.
11.
Create an air-traffic control system with base-class
Aircraftand various derived types. Create a Tower class
with a vector<Aircraft*>
that sends the appropriate
messages to the various aircraft under its control.
12.
Create a model of a greenhouse by inheriting various
types of Plant and building mechanisms into your
greenhouse that take care of the plants.
13.
In Early.cpp make Pet a pure abstract base class.
,
14.
In AddingVirtuals.cppmake all the member functions
,
of Pet pure virtuals, but provide a definition for name( ).
Fix Dog as necessary, using the base-class definition of
name( ).
15.
Write a small program to show the difference between
calling a virtual function inside a normal member
function and calling a virtual function inside a
constructor. The program should prove that the two calls
produce different results.
718
Thinking in C++
16.
Modify VirtualsInDestructors.cpp inheriting a class
by
from Derived and overriding f( ) and the destructor. In
main( ), create and upcast an object of your new type,
then delete it.
17.
Take Exercise 16 and add calls to f( ) in each destructor.
Explain what happens.
18.
Create a class that has a data member and a derived class
that adds another data member. Write a non-member
function that takes an object of the base class by value and
prints out the size of that object using sizeof. In main( )
create an object of the derived class, print out its size, and
then call your function. Explain what happens.
19.
Create a simple example of a virtual function call and
generate assembly output. Locate the assembly code for
the virtual call and trace and explain the code.
20.
Write a class with one virtual function and one non-
virtual function. Inherit a new class, make an object of
this class, and upcast to a pointer of the base-class type.
Use the clock( )function found in <ctime> (you'll need
to look this up in your local C library guide) to measure
the difference between a virtual call and non-virtual call.
You'll need to make multiple calls to each function inside
your timing loop in order to see the difference.
21.
Modify C14:Order.cppby adding a virtual function in
the base class of the CLASS macro (have it print
something) and by making the destructor virtual. Make
objects of the various subclasses and upcast them to the
base class. Verify that the virtual behavior works and
that proper construction and destruction takes place.
22.
Write a class with three overloaded virtual functions.
Inherit a new class from this and override one of the
functions. Create an object of your derived class. Can you
call all the base class functions through the derived-class
object? Upcast the address of the object to the base. Can
you call all three functions through the base? Remove the
overridden definition in the derived class. Now can you
15: Polymorphism & Virtual Functions
719
call all the base class functions through the derived-class
object?
23.
Modify VariantReturn.cpp show that its behavior
to
works with references as well as pointers.
24.
In Early.cpp how can you tell whether the compiler
,
makes the call using early or late binding? Determine the
case for your own compiler.
25.
Create a base class containing a clone( )function that
returns a pointer to a copy of the current object. Derive
two subclasses that override clone( )to return copies of
their specific types. In main( ), create and upcast objects
of your two derived types, then call clone( )for each and
verify that the cloned copies are the correct subtypes.
Experiment with your clone( )function so that you
return the base type, then try returning the exact derived
type. Can you think of situations in which the latter
approach is necessary?
26.
Modify OStackTest.cppby creating your own class, then
multiply-inheriting it with Object to create something
that can be placed into the Stack. Test your class in
main( ).
27.
Add a type called Tensor to
OperatorPolymorphism.cpp
.
28.
(Intermediate) Create a base class X with no data
members and no constructor, but with a virtual function.
Create a class Y that inherits from X, but without an
explicit constructor. Generate assembly code and
examine it to determine if a constructor is created and
called for X, and if so, what the code does. Explain what
you discover. X has no default constructor, so why
doesn't the compiler complain?
29.
(Intermediate) Modify Exercise 28 by writing
constructors for both classes so that each constructor calls
a virtual function. Generate assembly code. Determine
where the VPTR is being assigned inside each
constructor. Is the virtual mechanism being used by your
720
Thinking in C++
compiler inside the constructor? Establish why the local
version of the function is still being called.
30.
(Advanced) If function calls to an object passed by value
weren't early-bound, a virtual call might access parts that
didn't exist. Is this possible? Write some code to force a
virtual call, and see if this causes a crash. To explain the
behavior, examine what happens when you pass an
object by value.
31.
(Advanced) Find out exactly how much more time is
required for a virtual function call by going to your
processor's assembly-language information or other
technical manual and finding out the number of clock
states required for a simple call versus the number
required for the virtual function instructions.
32.
Determine the sizeof the VPTR for your implementation.
Now multiply-inherit two classes that contain virtual
functions. Did you get one VPTR or two in the derived
class?
33.
Create a class with data members and virtual functions.
Write a function that looks at the memory in an object of
your class and prints out the various pieces of it. To do
this you will need to experiment and iteratively discover
where the VPTR is located in the object.
34.
Pretend that virtual functions don't exist, and modify
Instrument4.cppso that it uses dynamic_castto make
the equivalent of the virtual calls. Explain why this is a
bad idea.
35.
Modify StaticHierarchyNavigation.cpp that instead of
so
using C++ RTTI you create your own RTTI via a virtual
function in the base class called whatAmI( )and an
enum type { Circles, Squares. };
36.
Start with PointerToMemberOperator.cpp
from Chapter
12 and show that polymorphism still works with
pointers-to-members, even if operator->*is overloaded.
15: Polymorphism & Virtual Functions
721
